AISI304 Rice Patteren Anti-slip Stainless Checker Plate 2.0 - 8.0mm
AISI304 Stainless Steel Checkered Plate Rice Patteren Anti-slip Stainless Steel pLate 2.0 - 8.0mm
| Product Name | Stainless Steel checkered plate |
| Thickness | 2mm-10mm |
| Width | 1010,1219,1250,1500mm,etc. |
| Length | 1000,2000,2440,2500,3000,5800,6000,or as your requirement. |
| Authentication | ISO9001-2008,SGS.BV |
| SurfaceTreatment | 2B NO.1 |
| Mainly Grade | 201 202 301 304 304L 309S 310S 316L 321 410 420 430 444 2205.etc |
| Contact | If you have any question,please feel free to contact me. we are sure your inquiry or requirements will get prompt attention. |
Stainless steel checkered plate is manufactured by cold rolling sheet and hot rolling stainless steel sheet. Owing to its premium modern and fashion appearance and excellent chemical properties, stainless steel diamond plate is frequently used in food industry, buildings, water heater, bathtub and dinnerware.
Checkered plate stainless steel comes in diverse sizes. The most popular size is 48" by 96", and 48" by 120", 60" by 120" are also common sizes. The thickness ranges from 1.0mm to 4.0mm.
Chemical composition of 304 stainless steel checkered plate
| 304 | C | Mn | P | S | Si | Cr | Ni |
| % | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.030 | ≤1.00 | 17.5–20.0 | 8.0-11 |
Maintenance of 304 stainless steel checkered plate
(1) Regular cleaning and maintenance
(2) Pay attention to prevent the occurrence of the phenomenon of surface scratches
(3) Use soap, weak detergent or warm water to remove surface dust, dirt
(4) In addition to the surface of the binder with alcohol or an organic solvent
(5) Use neutral detergent or ammonia solution in addition to surface oil
(6) With 10% nitric acid or abrasive detergent in addition to the surface of the embroider caused by the dirt.
Type of checkered Stainless Steel Plate
- stainless steel checker plate with small rice projections.
- stainless steel checker plate with flat strip projections.
- stainless steel checker plate with big rice projections.
- stainless steel checker plate with strip projections.
- stainless steel checker plates with rigid projections.
- stainless steel checker plate with flat round projections.
Diamond plate stainless steel features:
- Resistant to extremely high temperature;
- Available in any corrosion resistance and alkaline resistance.
- Never rust even exposed to water.
- Skid resistance.
- Very rigid surface can stand heavy wear and tear.
- Various patterns such as one bar, three bar, five bar.
The most popular products and specifications
- Diamond plate for bed rail cap to go around a 2013 toyota tocoma short bed single cab.
- One bar diamond plate steel size 12 inch × 48 inch.
- SUS 310S stainless steel checker plate 22mm to 25mm thickness, 1024mm × 3048mm sheets.
- SUS 253MA checker plate 8mm / 10mm / 15mm thickness, 1500mm × 4000mm plates.
- SS 304 chequer plate 3000mm × 1250mm × 4.5mm, 3000mm × 1250mm × 6mm, 3000mm × 1000mm × 6.0mm, 3000mm × 1000mm × 7.5mm.
- S.S 304 stainless steel diamond shaped chequered plates (non punched, original as european), 1500mm × 3000mm sheets, 40.mm, 5.0mm, 6.0mm thickness.
