ASTM B265 / SB265 Titanium Sheet and Plate Thickness 0.3 - 6.0mm 8.0 - 100mm Custom Any Size
ASTM B265 / SB265 Titanium Sheet and Plate Thickness 0.3 - 6.0mm 8.0 - 100mm Custom Any Size
Specification of TITANIUM Sheet Plate
| Standards | ASTM B265 / ASME SB265 |
| Thickness | 4mm-100mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, AS PER CUSTOMER’S REQUIREMENT. |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER’S REQUIREMENT. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard AS PER CUSTOMER’S REQUIREMENT. |
| Test Certificate | Chemical test, Fitting test, Alloy test, Radiography test, Macro and micro-test, Hydrostatic test, Impact test. |
| Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc. |
| Form | Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
Titanium Sheet and Plate. Extensive size range available for fabrication and engineering applications. Precision cut with custom surface finishes to meet your specifications.
Titanium Industries selection of Titanium Plate is illustrated below, used in applications across Aerospace, Defense, Medical, Industrial, and Oil & Gas industries. Used due to unique combination of high strength, light weight, corrosion resistance, biocompatibility, and higher temperature performance. Titanium Plate is available from .187" (4.749mm) thickness to 4" (101.6mm) thickness. Specifications:
- Titanium Grade 2 Plate: ASTM B265, ASTM F67, NACE MR0175
- Titanium Grade 4 Plate: AMS 4901, ASTM B265, ASTM F67, MIL-T-9046
- Titanium 6Al-4V Grade 5 Plate: AMS 2631, AMS 4911, MIL-T-9046, ASTM B265
- Titanium 6Al-4V Grade 23 ELI Plate: AMS 4907, ASTM F136, ASTM B265
Production Standards
ASTM B265 / SB265
DIN 17860
AMS 4901 / 4902
ASTM F67 / F136
Titanium Grades
Gr 1, 2, 3, 4
5(6Al-4V)
7(Ti-0.15Pd)
9(3Al-2.5V), 12
23 (6AL-4V ELI)
15V-3Al-3Sn-3Cr
Dimension Ranges (mm)
- Sheet
Thick: 0.3 – 300
Length: 1000 – 5600
Width: 400 – 2800
- Foil
Thick: 0.51 – 4.78
Width: 610 – 1220
Length: ≤ 6100
Surface Finishes
Polished, Mill, Pickling, Painted, Brushed or Blaste
Our supply includes Commercially Pure titanium along with Titanium Alloys including Grade 5 and Grade 9. We offer titanium sheets produced against all major production standards including ASTM (B265), GB, DIN and JS.
Titanium Coil
Standard Titanium Co. manufacturers pure and titanium alloy sheet metal to ASTM B265, ASME SB265 standards and other recognised international standards.
Titanium sheets and plates are available for the following grades, thickness ranges and rolling types.
| Grades | Rolling | Thickness Range | Delivery States |
|---|---|---|---|
| 1, 2, 3, 4, 7 | Hot Rolled | 0.3 < t < 4.0 | R M |
| Cold Rolled | 4.1 < t < 60 | Y M | |
| 12 | Hot Rolled | 0.5 < t < 4.0 | R M |
| Cold Rolled | 4.1 < t < 60 | Y M | |
| 5, 6 | Hot Rolled | 0.8 < t <4.0 | R M |
| Cold Rolled | 4.1 < t < 60 | Y M |
*Titanium plates are produced to: hot-rolled state (R), cold-rolled state (Y), annealed (M), quenched state (C).
