Alloy 200 (2.4066), N02200 Nickel Bar Bright Ni Bar Diameter 5mm - 200mm Pure Nickel
Alloy 200 (2.4066), N02200 Nickel Bar Bright Ni Bar Diameter 5mm - 200mm Pure Nickel
Specification of Nickel Bar
| Name | Nickel Round Bar |
| Grade | Alloy 200 / Alloy 201 / 2.4068 / 2.4066 |
| Density | 8.9g/cm3 |
| Diameter | 4 - 200mm or other special diameter as request |
| Length | 1m 2m 3m 4m 6m or cutting any length free |
| Surface | Bright |
| Lead time | 7 to 10 working days after the receipt of deposit |
| Other Shape | Plate, Pipe, Flat Bar, Coil |
| MOQ | 50 kgs |
| Payment terms | 30%TT for deposit, 70% balance before shipment |
| Price Term | FOB,CIF,EXW |
| Port of Loading | Shanghai Port |
| Deliver method | By Sea, UPS, DHL, Fedex |
| Packing | standard packing with plastic bags and strapped bundles, and can be customized; In bundles tied with steel strips. End plastic |
| caps, external packing by PVC or according to customer's request |
Description
2.4066 (alloy 200) is unalloyed nickel with excellent corrosion resistance and excellent stability against alkaline media and good mechanical characteristics in a broad temperature range. Shows good corrosion resistance under reducing conditions, e.g. hydrofluoric acid and hydrochloric acid. Shows good stability under oxidizing conditions (by creating a surface protection film). Material 2.4066 (alloy 200) is used in the chemical industry and petrochemical industry.
Our product range in 2.4066 (alloy 200) are tubes and pipes, fittings and flanges, accessories.
Grade Specification
| Material No. | 2.4066 |
|---|---|
| EN symbol (short) | Ni 99.2 |
| AISI/SAE | — |
| UNS | N 02200 |
| AFNOR | — |
| B.S. | 3072-3076(NA11) |
| alloy | alloy 200 |
| Registered work's label | |
| Standards | — |
Chemical composition ¹ |
||||||||
| C ≤ % |
Si ≤ % |
Mn ≤ % |
P ≤ % |
S ≤ % |
Cr % |
Mo % |
Ni % |
Mg ≤ % |
| 0,1 | 0,25 | 0,35 | 0,005 | 99,2 | 0,15 | |||
| Nb % |
Ti ≤ % |
Al % |
Co ≤ % |
Cu ≤ % |
N % |
Fe ≤ % |
Ce % |
Y ≤ % |
| 0,1 | 0,25 | 0,4 | ||||||
| ¹ in accordance with Key to Steel 2001 | ||||||||
Special characteristics |
||
| Temperature range | Density kg/dm³ | Hardness |
|---|---|---|
| 8,89 | ||
| very good corrosion resistance in reducting conditions | ||
Welding filler |
| covered rod electrode 2.4156 |
Main fields of application (depending on the specific conditions of use) |
| chemical industry, fluorine, hydrogen chloride, petrochemical industry, vaporisers for caustic soda, plant components for salt production, food industry |
| (all aforementioned specifications serve as a general orientation and have to be reviewed depending on the specific conditions of use) |
