ASTM A312 AISI316L / TP316L 316L Stainless Steel Pipe Tube Stright SS Pipe For Chemical
Price:
4000-5000 USD/Ton
MOQ:
500 kgs
Delivery Time:
5 - 12 days based on the quantity
Brand:
DELTA
Product Description
ASTM A312 AISI316L / TP316L 316L Stainless Steel Pipe Tube Stright SS Pipe for Chemical
Specification of 316L Stainless Steel Pipe
- Specifications : ASTM A358 / ASME SA358
- Outside Diameter : 6.00 mm OD up to 914.4 mm OD, Sizes up to 24" NB available Ex-stock, OD Size available Ex-stock
- Thickness : 0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
- Size : 1/2" NB - 24" NB
- Type : EFW
- Form: Round Pipes, Square Pipes, Rectangular Pipes.
- Length : Single Random, Double Random & Required Length
- End : Plain End, Beveled End, Treaded
Equivalent Grades of 316/ 316L Stainless Steel Pipe
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 316 | S31600 | 316S31 | 58H, 58J | 1.4401 | X5CrNiMo17-12-2 | 2347 | SUS 316 |
| 316L | S31603 | 316S11 | - | 1.4404 | X2CrNiMo17-12-2 | 2348 | SUS 316L |
Chemical Composition of 316/316L Stainless Steel Pipe
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 316 | min. max. |
- 0.08 |
- 2.0 |
- 0.75 |
- 0.045 |
- 0.03 |
16.0 18.0 |
2.00 3.00 |
10.0 14.0 |
- 0.10 |
| 316L | min. max. |
- 0.03 |
- 2.0 |
- 0.75 |
- 0.045 |
- 0.03 |
16.0 18.0 |
2.00 3.00 |
10.0 14.0 |
- 0.10 |
ASTM A312 SS 316/316L Stainless Steel PipeMechanical Properties
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 316 | 515 | 205 | 40 | 95 | 217 |
| 316L | 485 | 170 | 40 | 95 | 217 |
Standard specifications for stainless steel pipe
| Inch |
DN (mm) |
OD (mm) |
SCH5S | SCH10S | SCH10 | SCH20 | SCH30 | SCH40 | SCH60 | SCH80 | SCH100 | SCH120 |
| 1/8 | DN6 | 10.3 | 1.24 | 1.73 | 2.42 | |||||||
| 1/4 | DN8 | 13.7 | 1.65 | 2.24 | 3.02 | |||||||
| 3./8 | DN10 | 17.1 | 1.65 | 2.31 | 3.2 | |||||||
| 1/2 | DN15 | 21.3 | 1.65 | 2.11 | 2.77 | 3.73 | ||||||
| 3/4 | DN20 | 26.7 | 1.65 | 2.11 | 2.87 | 3.91 | ||||||
| 1 | DN25 | 33.4 | 1.65 | 2.77 | 3.38 | 4.55 | ||||||
| 1 1/4 | DN32 | 42.2 | 1.65 | 2.77 | 3.56 | 4.85 | ||||||
| 1 1/2 | DN40 | 48.3 | 1.65 | 2.77 | 3.68 | 5.05 | ||||||
| 2 | DN50 | 60.3 | 1.65 | 2.77 | 3.91 | 5.54 | ||||||
| 2 1/2 | DN65 | 73.0 | 2.11 | 3.05 | 5.16 | 7.01 | ||||||
| 3 | DN80 | 88.9 | 2.11 | 3.05 | 5.49 | 7.62 | ||||||
| 3 1/2 | DN90 | 101.6 | 2.11 | 3.05 | 5.74 | 8.08 | ||||||
| 4 | DN100 | 114.3 | 2.11 | 3.05 | 6.02 | 8.58 | 11.13 | |||||
| 5 | DN125 | 141.3 | 2.77 | 3.4 | 6.55 | 9.53 | 12.7 | |||||
| 6 | DN150 | 168.3 | 2.77 | 3.4 | 7.11 | 10.97 | 14.27 | |||||
| 8 | DN200 | 219.1 | 2.77 | 3.76 | 6.35 | 7.04 | 8.18 | 10.31 | 12.7 | 15.09 | 18.26 | |
| 10 | DN250 | 273.1 | 3.40 | 4.19 | 6.35 | 7.8 | 9.27 | 12.7 | 15.09 | 18.26 | 21.44 | |
| 12 | DN300 | 323.9 | 3.96 | 4.57 | 6.35 | 8.38 | 10.31 | 14.27 | 17.48 | 21.44 | 25.4 | |
| 14 | DN350 | 355.5 | 3.96 | 4.78 | 6.35 | 7.92 | 9.53 | 11.13 | 15.09 | 19.05 | 23.83 | 27.79 |
