Cold Drawn Hot Rolled 310S Stainless Steel Pipe Tube DN5 - DN200 SCH40S SCH80S SCH160S
Cold Drawn Hot Rolled 310S Stainless Steel Pipe Tube DN5 - DN200 SCH40S SCH80S SCH160S
Products Specification
| Standard | ASTM A213, ASTM A269, ASME SA213, ASME SA269 |
| Pipe Type | Bright Annealed Stainless Steel Tubing |
| Grades | 304, 304L, 316, 316L, 321, 310S, 2205, 2507 |
| Dimensions | Outer Diameter (OD): 1.00 mm to 76.2 mm |
| Wall Thickness | 0.2 mm to 6.0 mm |
| Length | Up to 12 meters (custom lengths available upon request) |
| Manufacturing Process | Cold Drawn, Bright Annealed, Seamless |
| Material Surface Finish | Bright Annealed (BA), Mirror Polished, No. 4 Finish |
| End Type | Plain End (PE), Beveled End (BE), Threaded End (TE) |
| Certifications | ISO 9001, EN 10204 3.1 / 3.2, PED, ASME |
High temperature resistant stainless steel pipe, also known as 310S (0Cr25Ni20) stainless steel, is an austenitic chromium-nickel stainless steel with good oxidation resistance and corrosion resistance. Because of the higher percentage of chromium and nickel, it has much better creep strength. It can continue to operate at high temperatures and has good high temperature resistance.
Cold drawn seamless pipe specifications: outer diameter 6mm---940mm; wall thickness 0.8mm---60mm. Plasma welding and argon arc welded pipe specifications: outer diameter 12mm---2540mm; wall thickness 0.5mm---30mm. The theoretical weight calculation formula of 310S stainless steel round tube: (outer diameter - wall thickness) × wall thickness × 0.02491 = KG/M
Chemical composition (%) of high temperature resistant 310S stainless steel pipe: Ni Nickel: 19.00-22.00 Cr Chromium: 24.00-26.00 Si Silicon ＜= 1.50 Mn Manganese ＜= 2.00 C Carbon ＜= 0.08 S Sulfur ＜= 0.030 P Phosphorus ＜= 0.035. Density: 8.0 g/cm3, mechanical properties after solution treatment: yield strength ≥ 205, tensile strength ≥ 520, elongation ≥ 40, hardness test: HBS ≤ 187, HRB ≤ 90, HV ≤ 200.
SS 310/310S Pipes Chemical Composition
| Element | SS 310 | SS 310S |
| C | 0.015 max | 0.08 max |
| Mn | 2.0 max | 2.0 max |
| Si | 0.15 max | 1.00 max |
| P | 0.020 max | 0.045 max |
| S | 0.015 max | 0.030 max |
| Cr | 24.00 - 26.00 | 24.00 - 26.00 |
| Mo | 0.10 max | 0.75 max |
| Ni | 19.00 - 21.00 | 19.00 - 21.00 |
| Fe | 54.7 min | 53.095 min |
Stainless Steel 310/310S Pipes Mechanical & Physical Properties
| Element | SS 310/310S |
| Density | 7.9 g/cm3 |
| Melting Point | 1402 °C (2555 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 40 % |
- Specifications:ASTM A/ASME SA213/A249/A269/A312/A358
- Dimensions:ASTM, ASME and API
- Size :1/8″NB TO 30″NB IN
- 310S Pipes & Tubes:1/2″ NB – 16″ NB
- Schedule:SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
- Type:Seamless / ERW / Welded / Fabricated / LSAW Pipes
- Specialized in:Large Diameter Size
- Length:Single Random, Double Random & Cut Length.
We can also provide the following types and services of plate and round steel:
Stock size sheets and planks
Stock length round bars
Plate and boards cut to size
Round steel cut to length
Cold forming of plates, plates and round bars
Other additional processing requirements (according to customer needs)
Our services are designed to meet the specific needs of our clients, ensuring that the materials supplied meet project requirements and are of high quality standard. We are committed to providing efficient, reliable service and ensuring timely delivery. If you have any needs about stock products or customized products, please feel free to contact us and we will serve you wholeheartedly.
