50mm 60mm 70mm 80mm 100mm Hastelloy C276 Round Bar Nickel Alloy EN 2.4819

Name: 50mm 60mm 70mm 80mm 100mm Hastelloy C276 Round Bar Nickel Alloy EN 2.4819
Brand: JIANGSU MITTEL STEEL INDUSTRIAL LIMITED

Price Negotiable

Price: 40-45 USD/Kg

MOQ: 500 kgs

Delivery Time: 5 - 12 days based on the quantity

Brand: DELTA

Product Description

50mm 60mm 70mm 80mm 100mm Hastelloy C276 Round Bar Nickel Alloy EN 2.4819

Quick Informations

More Specification Informations

Products Name	Hastelloy C276 Round bar, Nickel alloy round bar
Diameter	10 - 330mm
Length	Custom cutting any length as request
Surface	Black
Brand	DELTA
Service	cutting, bright polishing
MOQ	2 Kgs
Other Type	Sheet,plate, strip,coil,pipe.etc
Packing	waterproof paper , wooden box
Loading Port	Shanghai Port
Price term	EXW,FOB,CIF,CFR
Deliver time	within 12 days

Condition of Hastelloy C276 Round Bar

Grade

Hastelloy C276

0.010 max

1 max

0.08 max

2.5 max

0.04 max

4 – 7

15 – 17

Bal

14.5-16.5

0.03 max

3.0-4.5

0.35 max

ASME SB574 Round Bar Tolerance

NOMINAL SIZE	h5	h6	h7	h8	h9	H10	H11	h12
DIAMETER mm	h5	h6	h7	h8	h9	H10	H11	h12
~ to 3	+0.004/0	+0.006/0	+0.01/0	+0.014/0	+0.025/0	+0.04/0	+0.06/0	+0.1/0
over 10 to 18	+0.008/0	+0.011/0	+0.018/0	+0.027/0	+0.043/0	+0.07/0	+0.11/0	+0.18/0
over 3 to 6	+0.005/0	+0.008/0	+0.012/0	+0.018/0	+0.03/0	+0.048/0	+0.075/0	+0.12/0
over 18 to 30	+0.009/0	+0.013/0	+0.021/0	+0.033/0	+0.052/0	+0.084/0	+0.13/0	+0.21/0
over 30 to 50	+0.011/0	+0.016/0	+0.025/0	+0.039/0	+0.062/0	+0.1/0	+0.16/0	+0.25/0
over 6 to 10	+0.006/0	+0.009/0	+0.015/0	+0.022/0	+0.036/0	+0.058/0	+0.09/0	+0.15/0
over 80 to 120	+0.015/0	+0.022/0	+0.035/0	+0.054/0	+0.087/0	+0.14/0	+0.22/0	+0.35/0
over 50 to 80	+0.013/0	+0.019/0	+0.03/0	+0.046/0	+0.074/0	+0.12/0	+0.19/0	+0.3/0
over 180 to 250	+0.02/0	+0.029/0	+0.046/0	+0.072/0	+0.115/0	+0.185/0	+0.29/0	+0.46/0
over 120 to 180	+0.018/0	+0.025/0	+0.04/0	+0.063/0	+0.1/0	+0.16/0	+0.25/0	+0.4/0
