Inconel 718 Nickel Alloy Pipe Tube OD6 - 426mm With EN 10204-3.1 Certificate
Inconel 718 Nickel Alloy Pipe Tube OD6 - 426mm With EN 10204-3.1 Certificate
Products Specification
|
Model
|
Nickel Tubes Pipes
|
|||
|
Material Grade
|
Inconel 600, Inconel 601, Inconel 625, Inconel 690, Inconel 718, Inconel 725, etc
Incoloy 800, Incoloy 825, Incoloy 925, Incoloy 800H, Incoloy 800, Incoloy926(AL-6XN), etc
Hastelloy C276, Hastelloy C22, Hastelloy C2000, Hastelloy X, etc |
|||
|
Diameter
|
a) Capillary Tube Outer Diameter: 0.2mm-6.mm
Welding Tube Outer Diameter: 6.mm- 840mm
Seamless Tube Outer Diameter: 6mm-630mm
|
|||
|
b) Capillary Tube Wall Thickness: 0.02mm-2mm
Welding Tube Wall Thickness: 0.5-150mm
Seamless Tube Wall Thickness: 0.5-60mm
|
||||
|
c) Length: ≤500mm Or in coil
|
||||
|
Tolerance
|
a) Outer Diameter: +/- 0.01mm
|
|||
|
b) Thickness: +/- 0.01mm
|
||||
|
c) Length: +/- 0.1mm
|
||||
|
Surface Treatment
|
Polishing,Annealing, Bright, Pickling
|
|||
|
Type
|
Welded,Seamless
|
|||
|
Shape
|
Round,Square,Irregular
|
|||
|
Application
|
medical treatment, petroleum, aerospace, medical equipment, air conditioning, chemical industry, electronics, accessories, food machinery, power generation, pharmaceutical and other fields.
|
|||
Alloy 718 is a p recipitation hardened Nickel, Chromium alloy with excellent weld ability and resistant to post weld cracking, Used extensively through the nuclear and turbine industry..
Chemipetro supplies Alloy 718 in the following Product Forms:
Seamless pipe to ASTM B444 and ASME SB444
Welded pipe to ASTM B705 and ASME SB705
Flanges to ASTM B564 and ASME SB564
Fittings to ASTM B366 and ASME SB366
Bar to ASTM B446 and ASME SB446
Plate to ASTM B443 and ASME SB443
Chemical Composition
Nickel (plus cobalt) ......................................................99.0 min.
Copper........................................................................0.25 max.
Iron..............................................................................0.40 max.
Manganese .................................................................0.35 max.
Carbon........................................................................0.15 max.
Silicon .........................................................................0.35 max.
Sulfur ..........................................................................0.01 max
Packaging Details
1)Packing: plastic bag
2)Packed in bundle with non-woven fabrics/plastic woven bags
3)Carton case/wooden case
4)As customer's requirement
Port:
Shanghai Tianjin,Ningbo,Qingdao,etc
Lead time:
| Quantity(kilograms) | 1 - 100 | 101 - 200 | >200 |
| Lead time (days) | 7 | 10 | To be negotiated |
FAQ
Q. Are you a factory or trading company?
A. We are a factory company.
Q. How to ensure the quality of your products?
A. IS09000, client requirements, product standards, strict inspection to control raw material,production process and final
products
Q. How do you resolve the problem about your products?
A. Person of aging services: For customer complaints commissioner set up a special complaint handling,complaint issues
recorded the first time and find the relevant person in charge of the feedback and resolve. Details check our "Quality
corrective action report"
Q. What is the MOQ?
A. Sample order is acceptable, And some samples can be free.
Q. How long do you need the delivery time?
1)Supply within 5-10 days (product in our Stock list)
2)Custom products need to be calculated according to the quantity
Q.What 's your payment terms?
A. T/T,L/C at sight , Western Union
Q.How can we get your price ?
A. We need below information to quote for you:
1. Product Name
2. Standard
3. Material Grade (Chemical Composition)
4. Dimension
5. Quantity
6. The Drawing for Special Parts
