Precision SUS301 Stainless Steel Strip High Strength Cold Rolled Spring Hard Finish
Precision SUS301 Stainless Steel Strip High Strength, Cold Rolled Spring Hard Finish
Products Specification
| Product Name | SUS301 Stainless Steel Strips |
| Length | As required |
| Width | 3mm-1219mm or as required |
| Thickness | 0.15 - 3.0mm or as required |
| Standard | AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc. |
| Technique | Hot rolled / cold rolled |
| Surface Treatment | 2B or according to customer requirement |
| Thickness tolerance | ±0.01mm |
| Material | 201, 202, 301, 302, 303, 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S 309S, 410, 410S,420, 430, 431, 440A,904L |
| Application | It is widely used in high temperature applications, medical devices, building materials, chemistry, food industry, agriculture, ship components.It also applies to food, beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts, nuts, springs, and screen. |
| MOQ | 1tons.We also can accept sample order. |
| Shipment time | Within 15-20 workdays after receiving deposit or L/C |
| Export packing | Waterproof paper, and steel strip packed.Standard Export Seaworthy Package.Suit for all kinds of transport,or as required |
| Capacity | 250,000 tons/year |
SUS301 Stainless Steel Strip
Material Grade: SUS301 (AISI 301 equivalent)
Standard: JIS G 4309
Overview
SUS301 stainless steel strip is a high-strength austenitic stainless steel known for its excellent combination of corrosion resistance, formability, and elasticity. It is widely used in applications requiring durability, spring properties, and lightweight design.
Key Features
-
High Strength: Achieves superior tensile strength through cold working (1/4H, 1/2H, H, EH, and SEH tempers available).
-
Corrosion Resistance: Resists oxidation and atmospheric corrosion in mild environments.
-
Elasticity: Ideal for spring components and flexible applications.
-
Formability: Suitable for deep drawing, bending, and stamping processes.
-
Surface Finish Options: BA (Bright Annealed), 2B, No.4 (Brushed), or custom finishes.
Typical Applications
-
Spring washers, clips, and connectors
-
Electronic components (e.g., battery contacts, SIM card trays)
-
Automotive trim and fasteners
-
Medical instruments
-
Architectural decoration
Chemical Composition (% by weight)
| C | Si | Mn | P | S | Cr | Ni |
|---|---|---|---|---|---|---|
| ≤0.15 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.030 | 16.0-18.0 | 6.0-8.0 |
Mechanical Properties
| Temper | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (HV) |
|---|---|---|---|---|
| Annealed | 520-820 | ≥205 | ≥40 | ≤200 |
| 1/2H | 930-1130 | ≥650 | ≥25 | 250-310 |
Available Dimensions
-
Thickness: 0.05mm to 3.0mm
-
Width: 10mm to 600mm
-
Coil ID: 150mm/300mm (customizable)
Certifications:
-
RoHS compliant
-
Mill test certificates available
Packaging:
-
Moisture-proof paper + plastic film + wooden pallet
-
Custom packaging upon request
Customization:
Available in slit coils, precision-cut blanks, or pre-hardened tempers. Contact us for technical specifications or tailored solutions.
