Hot Rolled 329 Grade Stainless Steel Plate Enhanced Durability for Chemical and Food Industries
Hot Rolled 329 Grade Stainless Steel Plate Enhanced Durability for Chemical and Food Industries
Stainless Steel Sheet Specifications
| Name | 329 stainless steel Plate |
| Our Grade |
200 Series: 201 202 300 Series: 301 304,304L,304H,309S,310S,314,316L,316Ti,316H,316LN,317L,321,329,347 400 Series: 409L,410,410S,416,420,430,431,436L.439,441,443,444,445,446 Super Stainless Steel: 904L,926,254SMO,654SMO,15-5PH,17-4PH,17-7PH.etc Nickel Alloy: C276, C22,G35,Alloy X,Monel 400,K500,Inconel 600,601,617,625,718,Incoloy 800,800H,800HT,825.etc |
| Technique | Hot Rolled, Cold Rolled,Forged |
| Standard | JIS, AISI, ASTM, DIN, TUV, BV, SUS, etc |
| Thickness | 0.1 – 80.0mm |
| Width range | 10mm – 2000mm |
| Length | Customized |
| Finish | 2B, BA, No.4, 8k, Brushed,Hairline,PVD Coating,Sandblasted |
| Service | Laser Cutting, Bending |
| Sample | Available |
Overview
329 grade stainless steel plate is a duplex stainless steel that combines the benefits of both austenitic and ferritic structures. It offers excellent corrosion resistance, high strength, and superior resistance to stress corrosion cracking, making it ideal for demanding environments such as the chemical, petrochemical, marine, and food processing industries.
Key Parameters
| Property | Description |
|---|---|
| Grade | 329 (UNS S32900, EN 1.4460) |
| Manufacturing Process | Hot Rolled / Annealed / Pickled |
| Thickness Range | 3 mm – 120 mm |
| Width | Up to 2000 mm |
| Length | Customized up to 6000 mm or per customer request |
| Surface Finish | No.1, 2B, BA, HL, or customized |
| Form | Plate, Sheet, Coil, and Cut-to-size pieces |
Chemical Composition (%)
| Element | C | Cr | Ni | Mo | Mn | Si | P | S | N |
|---|---|---|---|---|---|---|---|---|---|
| Typical | ≤0.08 | 23–28 | 2–5 | 1–2 | ≤1.5 | ≤1.0 | ≤0.04 | ≤0.03 | ≤0.08 |
Mechanical Properties
| Property | Typical Value |
|---|---|
| Tensile Strength (MPa) | ≥650 |
| Yield Strength (0.2% Proof, MPa) | ≥450 |
| Elongation (%) | ≥25 |
| Hardness (HB) | ≤290 |
| Density (g/cm³) | 7.8 |
Standards and Specifications
-
ASTM: ASTM A240 / A240M
-
EN: EN 10088-2
-
JIS: JIS G4304 / G4305
-
GB/T: GB/T 4237
-
ASME: ASME SA240
Performance Features
-
Excellent resistance to pitting and crevice corrosion, especially in chloride-containing environments.
-
High tensile and yield strength, roughly twice that of common austenitic stainless steels like 304 and 316.
-
Superior resistance to intergranular corrosion and stress corrosion cracking.
-
Good weldability and formability with proper procedures.
-
Stable performance in both oxidizing and reducing conditions.
Applications
329 stainless steel plate is widely used in environments that require both strength and corrosion resistance:
-
Chemical processing equipment – heat exchangers, pressure vessels, piping systems
-
Food and beverage industry – tanks, mixing vessels, conveyors
-
Marine and offshore applications – seawater cooling systems, pumps, valves
-
Pulp and paper industry – bleach washers, digesters
-
Oil and gas industry – refinery components, separators, pipelines
