0.8mm 65Mn Mining Vibrating Stainless Steel Crimped Wire Mesh High Manganese
0.8mm 65Mn Mining Vibrating Stainless Steel Crimped Wire Mesh High Manganese
Specifications of stainless steel crimped wire mesh:
- Materials: stainless steel 301, 302, 304, 304L, 316, 316L, 321.
- Mesh width: up to 2000 mm.
- Aperture width: 10-120 mm in the case of multi-notch meshes and 4-40 mm in the case of single-notch meshes.
- Weaving method: crimped before weaving.
- Surface treatment: pickling and passivation, polishing, galvanized.
Frame:
- Cut the edges;
- Bent edges;
- Sheathed hooks.
Packing:
- Sheets on pallets or in wooden cases;
- Rolls wrapped with waterproof paper and plastic film.
| Wire Gauge | Wire Diameter | Mesh/Inch | Aperture | Weight |
| SWG | (mm) | (mm) | (kg/m2) | |
| 14 | 2 | 21 | 1 | 4.2 |
| 8 | 4.05 | 18 | 1 | 15 |
| 25 | 0.5 | 20 | 0.61 | 2.6 |
| 23 | 0.61 | 18 | 0.8 | 3.4 |
| 24 | 0.55 | 16 | 0.1 | 2.5 |
| 24 | 0.55 | 14 | 0.12 | 4 |
| 22 | 0.71 | 12 | 0.14 | 2.94 |
| 19 | 1 | 2.3 | 0.18 | 1.45 |
| 6 | 4.8 | 1.2 | 2 | 20 |
| 6 | 4.8 | 1 | 2 | 20 |
| 6 | 4.8 | 0.7 | 3 | 14 |
| 14 | 2 | 5.08 | 0.3 | 12 |
| 14 | 2 | 2.1 | 1 | 2.5 |
| 14 | 2 | 3.6 | 1.5 | 1.9 |
Stainless steel crimped wire mesh features:
- Great strength and solid structure;
- Good rust and corrosion resistance;
- High loading capacity;
- Long service life;
- Beautiful surface.
- Stainless steel crimped wire mesh applications:
- Serves as vibrating screen, filter element, infill panel, barbecue grill, baking rack;
- Used in mining, chemical, petroleum, and construction industries;
- Designed into decoration, and artwork.
