Goodwe Inverter MS G3 Series GW 7KW 10KW On Grid Solar Inverter

Price Negotiable
Price: Negotiable
MOQ: Negotiable
Delivery Time: 7-15working days
Brand: kvou
Product Description

Low Price Goodwe Inverter MS G3 Series GW7-10KW on Grid Solar Inverter





Goodway MS G3 series adopts a new generation of appearance design and a new topology structure, fully meets the market demand for high-power single-phase household models, and is suitable for houses with large roof areas. It is suitable for houses with large roof areas, and can significantly reduce the system cost and operation and maintenance cost of multiple small-power single-phase inverters while guaranteeing the revenue.

The series includes three power bands of 7/8/10kW, with a maximum input current of 20A, adapting to a variety of high-power components on the market, a maximum of 1.55 times the DC overmatching capability, support for DC arc pulling protection, AC and DC surge secondary protection (DC side lightning alarm) while integrating more safety protection functions, comprehensive hardware and software protection, and enjoying the intelligent and safe use of electricity.



Specification
SDT Series (THREE PHASE)
GW7000-MS-C30
GW8000-MS-C30
GW10K-MS-C30
PV String Input Data
Max. DC Input Voltage (V)
600
MPPT Range (V)
40~560
Start-up Voltage (V)
50
Nominal DC Input Voltage (V)
360
Max. Input Current (A)
20
Max. Short Current (A)
25
No. of MPP Trackers
2
No. of Input Strings per Tracker
1
AC Output Data
Nominal Output Power (W)
7,000
8,000
10,000
Max. Output Apparent Power (VA)
7,700
8,800
10,000
Nominal Output Voltage (V)
220
Nominal Output Frequency (Hz)
50
Max. Output Current (A)
33.5
38.3
45.5
Output Power Factor
~1 (Adjustable from 0.8 leading to 0.8 lagging)
Output THDi (@Nominal Output)
<3%
