3kva 5kva Solar Inverter 24v 48v Hybrid Inverter For Home Solar Power System

Price Negotiable
Price: Negotiable
MOQ: Negotiable
Delivery Time: 7-15working days
Brand: kvou
Product Description

3kva 5kva solar inverter 24v 48v wholesale price solar panel hybrid inverter for home solar power system



FUNCTION


ECO-MODE
OPTIONAL


WIFI  OPTIONAL


98%MPPT
EFFCIENCY


MPPT/PWM  OPTIONAL


PURE SINE WAVE
OUTPUT
60A SOLAR CHARGE
CURRENT



Product Parameters
Model
1000VA
1500VA
2000VA
3000VA
5000VA
Input Voltage(DC)
12V/24V
12V/24V
12V/24V
24V/48V
24V/48V
Nominal Voltage
220VAC(Standard)
Rated Power
800W
1200W
1600W
2400W
4000W
Waveform
Pure Sine Wave
Battery Type
VRLA / GEL /GEL DEEP CYCLE/LITHIUM
Maximum pv array power
12V:800W / 24V:1600W/ 48V:3200W
PV Input Voltage Range (PWM Controller)
12V:MPPT 15V-150VDC / PWM 15V-30VDC
24V:MPPT 30V-150VDC / PWM 30V-60VDC
48V:MPPT 60V-150VDC / PWM 60V-105VDC
Maximum solar charging current
60A
Maximum AC charging current
15A/8A
30A/15A
40A/20A
30A/15A
42A/21A
Transfer Time
<10ms(UPS mode)/<20ms (INV mode)
Load peak ratio
(MAX)3:1
Static power(W)
5W
11.5W
13W
15W
20W
Protections
Power supply: Input overcurrent protector







FAQ:





1. If the inverter is dirty, can I wipe it clean with a damp towel? Can I wash it with water?

It is strictly prohibited to use wet towel to wipe or wash with water when the inverter is running and working with electricity. If the surface of the inverter is dirty, you need to disconnect all AC and DC power, unplug all terminals, wait for 5-10 minutes, and then use a dry towel dipped in organic volatile cleaner to clean it.



2. I have a child who is very naughty and often climbs up the inverter to play. Will it be okay?

The inverter is rechargeable and will get hot when working. It is strictly prohibited for children to play on top of the inverter to prevent danger!



3. Will the inverter radiate when installed indoors, and will it affect people's health?

The solar inverter has passed the strict test of CE, there is no radiation harm, it will not affect your health.



4. I heard that the inverter can be connected to GPRS, can I access the internet through the inverter?

When the inverter is connected to GPRS, it uploads data through GPRS. It has no router function to transmit Wi-Fi signal.



5. Can I press the buttons on the display of the inverter randomly? What should I do if I press them randomly?

The buttons on the inverter are for customers to check the inverter parameters. You can check the relevant parameters according to the steps in the manual. If you accidentally press the wrong button, you can also restore the inverter to the previous operation state by consulting the after-sales staff or checking the manual.



6. What should I do if the connecting wire of the inverter is bitten by mice?

If the inverter's connecting wire is bitten off, please call the after-sales personnel to deal with it on site immediately. Please do not handle it privately to avoid danger.



7. The solar inverter is so expensive, if it is installed outdoors, will it be stolen by thieves?

Solar inverters are usually equipped with anti-theft devices.



8. In order not to be stolen by thieves, how about I design a sealed anti-theft box for the inverter?

The inverter will generate heat when working. If it is installed in a sealed anti-theft box, it will make the inverter not dissipate heat smoothly. High temperature will reduce the output power of the inverter and also affect the life of the inverter. Therefore, installing a sealed anti-theft box is not recommended.



9. How do I install my solar inverter?

When installing your solar inverter, please avoid installing the inverter in the following locations:

1. Places under direct sunlight.

2. Places with poor ventilation.

3. Locations that will be exposed to rain.

4. Locations filled with debris.



Please feel free to install in other locations. However, we recommend users to install the inverter indoors. Solar inverters installed outdoors should be careful to avoid rain and lightning strikes.
