1. Structure Characters:
* Water proof layer between steel tape and cable core
* “8”Figure cross section
* Steel messenger wire
* Double coated PE corrugated steeltape under PE sheath
2.Properties:
* Excellent wter proof layer
* Steel tape armored, excellent anti-crush properties
* Good anti-bullet properties
* Messenger wire as the supoort member made excellent anti-pull performance and easy installation
Single Mode 24 Core Armoured Fiber Optic Cable GYXTC8S 1km
Price:
$0.08 - $0.10/ meter
MOQ:
1 Roll
Delivery Time:
Negotiable
Brand:
Jiangnan
Product Description
Product Details
The structure of GYTC8S optical cable is to put 250um optical fiber into a loose tube made of high modulus material, and the loose tube is filled with waterproof compound. The center of the cable core is a metal reinforcing core, loose tubes (and filling ropes) are twisted around the central reinforcing core to form a compact and circular cable core, and the cable core is longitudinally wrapped with a layer of plastic-coated steel strip (PSP), and steel wire The stranded wires are integrated into a figure-eight polyethylene sheath.
Cable Data
Specifications
| Number of cores | structure | outer diameter | weight(kg/km) | Tensile force(N) | Flattening force(N) | bending radius(mm) | ||||
| (mm) | long term short term | long term short term | static dynamic | |||||||
| 2-30 | 1+5 | 6.4×9.8 | 139 | 1500 | 5000 | 300 | 1000 | 10D | 20D | |
| 32-36 | 1+6 | 6.4×10.3 | 152 | 1500 | 5000 | 300 | 1000 | 10D | 20D | |
| 38-60 | 1+5 | 6.4×10.7 | 152 | 1500 | 5000 | 300 | 1000 | 10D | 20D | |
| 62-72 | 1+6 | 6.4×10.8 | 172 | 1500 | 5000 | 300 | 1000 | 10D | 20D | |
| 74-84 | 1+7 | 6.4×11.3 | 186 | 1500 | 5000 | 300 | 1000 | 10D | 20D | |
| 86-96 | 1+8 | 6.4×12.9 | 198 | 1500 | 5000 | 300 | 1000 | 10D | 20D | |
Product Show
FAQ
