N6 N5 N4 Pure Nickel Alloy Corrosion Resistance Rod / Pipe / Plate / Wire / Strip
KX N6 N5 N4 Pure Nickel Strip Based Alloys Light Rod Mechanical Manufacturing For Pure Nickel
Product Description and Application
N6,N5.N4 is also known as pure nickel
Pure nickel has stable chemical properties. It will not react with oxygen at room temperature but there is a slight oxidation when the temperature reaches 500℃. Because nickel has a significant passivation tendency, it also shows good corrosion resistance in alkaline environment and non-oxidizing inorganic acid environment at room temperature. The standard electrode potential of nickel is very similar with that of hydrogen, so it is difficult to escape hydrogen in a non-oxidizing environment. The corrosion rate of nickel increases sharply in the presence of oxidant and is also unstable in acetic acid. Pure nickel has excellent machining properties, good shaping and ductility, which can be processed into plate, strip, pipe, wire, bar and so on.
Process Performance and Requirements
- Product Fusion Process
Vacuum Induction Furnace(VIM) and Electroslag Remelting Furnace(ESR)
- Product Chemical Composition
| Type | Grade | Chemical Composition (Mass Fraction)% | ||||||||||||||||
| Ni+Co | Cu | Si | Mn | C | Mg | S | P | Fe | Pb | Bi | As | Sb | Zn | Cd | Sn | Rem | ||
| Pure Nickel | N2 | 99.98a | 0.001 | 0.003 | 0.002 | 0.005 | 0.003 | 0.001 | 0.001 | 0.007 | 0.0003 | 0.0003 | 0.001 | 0.0003 | 0.002 | 0.0003 | 0.001 | 0.02 |
| N4 | 99.9a | 0.015 | 0.03 | 0.002 | 0.01 | 0.01 | 0.001 | 0.001 | 0.04 | 0.001 | 0.001 | 0.001 | 0.001 | 0.005 | 0.001 | 0.001 | 0.1 | |
| N5 | 99.0a | 0.25 | 0.35 | 0.35 | 0.02 | --- | 0.01 | --- | 0.40 | --- | --- | --- | --- | --- | --- | --- | --- | |
| N6 | 99.5a | 0.10 | 0.10 | 0.05 | 0.10 | 0.10 | 0.005 | 0.002 | 0.10 | 0.002 | 0.002 | 0.002 | 0.002 | 0.007 | 0.002 | 0.002 | 0.5 | |
| N7 | 99.0a | 0.25 | 0.35 | 0.35 | 0.15 | --- | 0.01 | --- | 0.40 | --- | --- | --- | --- | --- | --- | --- | --- | |
| N8 | 99.0a | 0.15 | 0.15 | 0.20 | 0.20 | 0.10 | 0.015 | --- | 0.30 | --- | --- | --- | --- | --- | --- | --- | 1.0 | |
| N9 | 99.63a | 0.25 | 0.35 | 0.35 | 0.02 | 0.10 | 0.005 | 0.002 | 0.4 | 0.002 | 0.002 | 0.002 | 0.002 | 0.007 | 0.002 | 0.002 | 0.5 | |
- Product Physical Property
| Density | Melting Point | Boiling Point | Coefficient of Linear Expansion | Thermal Conductivity | Specific Heat | Resistivity |
| 8.902/cm3 | 1453℃ | 2730℃ | 13.3um/m·K | 82.9W/m·k | 0.47k1/kg.k | 68.44n Ω.m |
- Product Mechanical Property
| State |
Tensile Strength RmN/mm2 |
Yield Strength Rp0.2N/mm2 |
Elongation As% |
Brinell Hardness HB |
| Hot Rolling | 60~85 | 15~45 | 35~55 | 45~80 |
-
Grade Comparison Table
|
Type
|
Grade | GB/T 15007 Grade | ASTM Grade | ISO Grade |
| Pure Nickel | N2 | --- | --- | --- |
| N4 | --- | --- | --- | |
| N5 | --- | N02201 | NW2201 | |
| N6 | --- | --- | --- | |
| N7 | --- | N02200 | NW2200 | |
| N8 | --- | --- | --- | |
| N9 | --- | --- | --- |
- Productive Process
-
Professional Customization
| Cold-drawn Wire | ¢0.3~¢18mm(Delivery in rolls or trays) |
| Hot-Rolling Wire | ¢5.5~¢20mm(Delivery in rolls) |
| Strip | thickness 0.1~4.5*width 6~350mm(Supply in rolls or straight strips) |
| Smooth Forged Rod on a Lathe |
¢60~350mm,L800-2500mm |
| Hot-rolled Burnishing | ¢20~80mm,L1000-5000mm |
| Cold Drawn and Burnishing | ¢2.5~18mm,L1000-8000mm |
| Seamless Tube | ¢1~275mm,wall thickness 0.2~30,L1000-8000mm |
