Grade 5 Grade 9 Titanium Alloy Sheet Titanium In Aerospace Industry Marine Energy
Grade 5, Grade 9 Alloy Titanium Plate Sheet For Petrochemical Industry For Aerospace Automotive Medical Marine Energy
*If you have any requirements for customized titanium plate, we would be delighted to further discuss the technical specifications with you and provide a quotation.
*Our production capacity is efficient, and our logistics channels are well-developed. We can deliver products via international express to any corner of the globe within 3 to 7 days.
Titanium plate specifications & parameters |
|
|
Product name |
Titanium plate sheet |
|
Application field |
Aerospace, Automotive, Shipbuilding, Defense, Structural Engineering |
|
Available size |
Thickness: 5-200mm; Width: 500-3000mm; Length: 1000-12000mm |
|
Grade |
Ti-6Al-4V, Ti-6Al-7Nb, Ti-3Al-2.5V, Grade 5, Grade 9 |
|
Production stadards |
ASTM B265, ASME SB-265, ISO 5832 |
|
Tolerance |
Thickness: +/- 0.1mm; Width: +/- 0.5mm; Length: +/- 1.0mm Hot rolling, Cold rolling |
|
Rolling process |
Hot rolling, cold rolling |
|
Surface process |
Polished, Sandblasted, Pickled |
|
Delivery time |
15-20days |
|
Key words |
|
Titanium Alloy Plate: A Comprehensive Guide to Its Versatility Across Industries
Introduction
Titanium alloy plates, produced by reputable brands like BaseTi, offer a range of groundbreaking solutions across a multitude of industries. From aerospace to medical fields, these plates exhibit unparalleled mechanical properties, making them the first choice for specialized applications.
-
Aerospace Industry
In the aerospace industry, weight and strength are crucial factors. The tensile strength of titanium alloy plates, often exceeding 130,000 PSI, significantly reduces the overall weight of aircraft while maintaining structural integrity. For example, a Boeing 787 uses about 15 tons of titanium.
-
Medical Sector
In medical applications, titanium alloy plates are predominantly used in orthopedic implants and prostheses. With a Young's Modulus closer to that of human bone and excellent biocompatibility, they offer the ideal balance between strength and flexibility. BaseTi's products, compliant with ASTM F136 standards, are the gold standard for medical-grade titanium plates.
-
Energy Sector
Corrosion resistance, especially against seawater, makes titanium alloy plates indispensable in offshore drilling platforms and desalination plants. The corrosion rate is as low as 0.002 inches per year, thus ensuring long-lasting performance.
-
Automotive Industry
In high-performance vehicles, titanium alloy plates are used for their excellent strength-to-weight ratio and resistance to high temperatures. It can withstand temperatures up to 800°F, making it a superior alternative to traditional steel.
-
Chemical Processing
The excellent resistance to acid and alkali solutions makes these plates ideal for chemical reactors and heat exchangers. It can withstand a variety of harsh chemicals, including hydrochloric acid and sulfuric acid.
Conclusion
Titanium alloy plates offer solutions that are not only high-performing but also cost-effective in the long run. Companies like BaseTi continue to push the boundaries of what is possible with this incredible material.
| Grade | ASTM Standard | Tensile Strength (psi) | Yield Strength (psi) | Elongation (%) | Hardness (HV) | Thermal Conductivity (W/mK) | Density (g/cm³) |
|---|---|---|---|---|---|---|---|
| Ti6Al4V (Grade 5) | ASTM B265, ISO 5832 | 130,000 – 150,000 | 120,000 | 10 - 15 | 330-370 | 6.7 | 4.43 |
| Ti3Al2.5V (Grade 9) | ASTM B265, ISO 5832 | 90,000 – 120,000 | 70,000 | 15 - 20 | 300-340 | 7.2 | 4.48 |
| Commercially Pure (Gr 2) | ASTM B265, ISO 5832 | 50,000 – 80,000 | 40,000 | 20 - 25 | 150-220 | 21.9 | 4.51 |
This tabulation incorporates several crucial parameters including tensile strength, yield strength, elongation, hardness, thermal conductivity, and density, providing a 360-degree view of the material properties under various grades and standards such as ASTM B265 and ISO 5832. At BaseTi, we adhere to these international standards, ensuring our customers receive the highest quality Titanium Alloy Composite Thick Plates.
