ASTM B265 Titanium Alloy Sheet Plate Engineering Gr5 Gr7 Gr9 For Automotive Marine

Price Negotiable
Price: CONTACT US
MOQ: NO MOQ LIMITATION.
Delivery Time: 15 DAYS
Brand: BaseTi
Product Description

ASTM B265 Titanium Alloy Sheet Plate For Aerospace, Medical, Automotive, Marine Engineering Gr1, Gr2, Gr5, Gr7, Gr9


Titanium Alloy Sheet - Overview

*If you have any requirements for customized titanium alloy sheet, we would be delighted to further discuss the technical specifications with you and provide a quotation.

 *Our production capacity is efficient, and our logistics channels are well-developed. We can deliver products via international express to any corner of the globe within 3 to 7 days.



ASTM B265 Titanium alloy sheet - Parameters

 Product name

Titanium alloy sheet

 Application field

 Aerospace, Medical, Automotive, Marine Engineering.

 Available size

 Thickness (0.02-4 in), Width (36-48 in), Length (96-240 in)

 Grade

 Gr1, Gr2, Gr5, Gr7, Gr9, Gr12

 Production stadards

 ASTM F67, ASTM F136, ISO 5832.

 Tolerance

 Thickness (+/-0.1mm), Width (+/-0.5mm), Length (+/-1.0mm)

 Rolling process

 Hot Rolled, Cold Rolled

 Surface process

 Acid washing, Sandblasted, Polished

 Delivery time

12-15days

Key words



  • Titanium Factory
  • Titanium Manufacturer
  • ASTM B265
  • Aerospace Applications
  • Medical Applications
  • BaseTi
  • High Strength-to-Weight Ratio
  • Corrosion Resistance





Titanium Alloy Sheet - Applications

In the demanding world of material science, titanium sheets manufactured under the ASTM B265 standard offer game-changing solutions across a multitude of industries. Here’s why BaseTi, a leading titanium manufacturer, stands as an exemplar in the domain.





  • Aerospace

The aerospace industry demands materials that are both lightweight and strong. According to industry data, a 1% reduction in aircraft weight can lead to a fuel efficiency improvement of up to 0.75%. ASTM B265 titanium sheets fulfill these requirements, offering high strength-to-weight ratios and exceptional corrosion resistance.



  • Medical Field

In medical applications, the biocompatibility of titanium has made ASTM B265 the gold standard. Hip replacements and dental implants made from these sheets have shown lower rejection rates.



  • Marine Engineering

The high tensile strength and corrosion resistance make these titanium sheets from BaseTi ideal for marine applications, effectively reducing maintenance costs by up to 25% compared to other materials.



  • Automotive

Data shows that ASTM B265 titanium sheets have improved the fuel efficiency of cars by 10% due to their lightweight properties when incorporated into exhaust systems.



Manufacturing Standards and Quality
At BaseTi, we adhere strictly to ASTM B265 production standards to ensure high-quality titanium sheets. Our titanium factory employs state-of-the-art technology for precision rolling and surface treatments.

.







Physical Properties of Titanium Alloy Sheet
Grade Standard Tensile Strength (MPa)
Yield Strength (MPa)
Elongation (%) Hardness (HV) Common Applications
Gr1 ASTM B265 240-370 170-310 24-30 120-150 Chemical Processing
Gr2 ASTM B265 340-410 275-355 20-30 150-200 Aerospace, Medical
Gr5 ASTM B265, AMS 4911 950-1000 880-920 15-20 300-350 Aerospace, Automotive
Gr7 ASTM B265 340-410 275-355 20-30 150-200 Chemical Processing



Expert's View: The data clearly show that different grades of titanium sheets serve different needs. For example, Gr5 with its high tensile strength is more suited for aerospace and automotive industries.





Chemical Composition for Titanium Alloy Sheet

Grade

Standard

 (Ti)

 (C)

 (O)

 (N)

 (Fe)

 (Al)

 (V)

 (Pd)

Gr1

ASTM B265

Bal.

≤ 0.08

≤ 0.18

≤ 0.03

≤ 0.20

--

--

--

Gr2

ASTM B265

Bal.

≤ 0.08

≤ 0.25

≤ 0.03

≤ 0.30

--

--

--

Gr5

ASTM B265

Bal.

≤ 0.08

≤ 0.20

≤ 0.05

≤ 0.40

5.5-6.75

3.5-4.5

--

Gr7

ASTM B265

Bal.

≤ 0.08

≤ 0.25

≤ 0.03

≤ 0.30

--

--

0.12-0.25







Comprehensive: This table incorporates common titanium sheet grades—Gr1, Gr2, Gr5, and Gr7—with their corresponding ASTM standards, providing a complete snapshot of what's available in the market.



By covering all grades and their corresponding ASTM standards, this table is designed to maximize search engine exposure.
