Machinery Packaging Machine Blister Packaging Machines

Tablets Alu Alu Blister Packing Machine 380V 50Hz 3.8KW

Price Negotiable
Price: USD11000/unit
MOQ: 1unit
Delivery Time: 20-25 work days
Brand: LEIYUE
Product Description

Cat and dog pet insect repellent tablets Alu Alu Blister Packing Machine





Cat and dog pet insect repellent tablets Alu Alu Blister Packing Machine is a specialized automated machinery used for packaging cat and dog pet deworming tablets, using aluminum-aluminum blister packaging. Its main working principle is to feed the aluminum-aluminum blister roll into the equipment, then through forming, filling, sealing, and other processes, the deworming tablets are filled into the blister packaging material, and finally formed into a sealed aluminum-aluminum packaging to ensure the quality and safety of the medication.





Technical Specifications:



Model DPP-150
Cutting frequency 10-30 times/min
Capacity 1000-2000 plates/h
Max shaping areas and depth 140*110*14mm
Air pressure 0.4-0.6MPa
Power supply 380V/50Hz 3.8KW
Main motor power 1.5KW
PVC hard pieces (width)155*(thickness)0.25-0.5mm
PTP aluminum foil (width)155*(thickness)0.025-0.05mm
Dialysis paper (width)155*50-100g
Mould cooling tap water or recycling water
Machine dimensions 2315*635*1405mm
Net weight 820kg



 Electronic cigarette Alu PVC vacuum packaging machine Workflow:



Heating of PVC material→PVC blow molding→Automatic capsule feeder→Aluminum foil heat sealing→Finished product punching and cutting







The application scenarios of a flat packaging machine are as follows:



1,Pharmaceutical industry: A flat packaging machine can be used to manufacture drug packaging, such as tablets, capsules, and powders.

2,Food industry: A flat packaging machine can be used to manufacture food packaging, such as chocolate, candy, cookies, coffee, etc.

3,Cosmetics industry: A flat packaging machine can be used to manufacture cosmetic packaging, such as creams, shampoos, perfumes, lipsticks, etc.

4,Other industries: A flat packaging machine can also be used to manufacture packaging for other types of products, such as electronic products, medical equipment, hardware accessories, etc.



The flat packaging machine can be adapted to various packaging specifications, and different molds and packaging materials can be selected according to product needs. It has high production efficiency and stable packaging quality, and is widely used in various industries' production and manufacturing processes.
