15S ESS Solution Safe Reliable 48V 280Ah LiFePO4 Battery For Energy Storage
Product Description
Safe & Reliable 15S 48V 200Ah LiFePO4 Battery for Energy Storage
This battery is a versatile and convenient energy storage solution designed for mobility. It finds applications in various industries where portability and ease of transport are crucial. Here is a brief introduction to this battery pack:
Voltage and Capacity: This LiFePO4 battery pack operates at a voltage of 48V and has a capacity of 280Ah. The 48V rating makes it suitable for a range of applications, including electric vehicles, renewable energy systems, and backup power systems.
LiFePO4 Chemistry: The battery pack utilizes lithium iron phosphate (LiFePO4) as the positive electrode material. LiFePO4 chemistry offers excellent thermal stability, enhanced safety, and a long cycle life. It ensures reliable and stable power delivery.
Portable Design with Wheels: The battery pack is equipped with wheels, enabling easy mobility and transportation. The built-in wheels allow for effortless movement, making it convenient to transport the battery pack to different locations as needed.
High Energy Density: LiFePO4 batteries have a high energy density, allowing them to store a significant amount of energy in a compact size. This high energy density ensures prolonged power supply while maintaining a compact and lightweight form factor.
Environmental Friendliness and Safety: LiFePO4 batteries are considered environmentally friendly and safe. They are free from toxic heavy metals and provide excellent thermal stability, minimizing the risk of thermal runaway or combustion.
| Items | Specification |
|---|---|
| Cell Type | LiFePO4 (Customizable: LiFePO4 / NCM / Prismatic / Cylindrical) |
| Nominal Voltage | 48V |
| Battery Capacity | 280Ah |
| Nominal Energy | 13.44kWh (13440Wh) |
| Dimension [L*W*H] | 560*560*320 mm (220.5*22.05*12.60 inch) (Customizable Dimension) |
| Weight | ≈105kg (231.48 lbs) |
| Working Voltage | 37.5V~54.75V |
| Charge Voltage | 54.75V |
| Discharge Cut-off Voltage | 37.5V |
| Maximum Charge Current | 200A Continuous |
| Maximum Discharge Current | 200AContinuous |
| Fast Charging | Supports Fast Charging |
| Charging Temperature | 0~55°C (32℉~131℉) |
| Discharging Temperature | -20~60°C (-4℉~140℉) |
| Operating Humidity Range | <30% |
| Series/Parallel Number | 15S1P |
| Max. Parallel Connection | 16 |
| Cycle Life (25°C / 77℉@60% DOD) | >8000 Cycles |
| Cycle Life (25°C / 77℉@80% DOD) | >6000 Cycles |
| Self-Discharge Rate | <3% per month (25°C / 77℉) |
| IP Grade | IP21 (Higher grade optional) |
| Battery Case | Steel |
| Battery Base Wheels | 4 |
| Monitoring & Protection | Smart BMS: Overcharge / OverDischarge / Overcurrent / OverTemperature / ShortCircuit |
| Communication | RS485 / CAN |
| Optional Functions | Bluetooth / WiFi / Circuit Breaker / Heating / Active Balance / LED Touch Screen / APP |
| Accessories | Inverter Power Cable, Parallel Cable, Communication Cable, Grounding Wire |
| Compatible Inverters | Victron / GOODWE / Solis / Growatt / SMA / SAJ / Luxpower / SRNE / Deye / Voltronic, etc. |
| Color | White / Gray / Black |
| Design Life | 20 Years |
| Warranty | 5 Years |
| User Manual | With the Battery Packaging |
| Certification & Safety Standard | UL / FCC / CE / IEC / RoHS / UN38.3 / MSDS |
Advantages of lithium batteries
High energy density - Lithium-ion batteries can store more energy per unit weight and volume compared to other battery technologies.
Long lifespan - Lithium-ion batteries can withstand hundreds to thousands of charge cycles over their lifetime.
No memory effect - Lithium-ion batteries do not require full discharge before recharging like nickel-cadmium batteries.
Low self-discharge - Lithium-ion batteries retain their charge for a long time even when not in use.
Application
CUSTOM BATTERY SOLUTIONS
Redway Battery specializes in providing a diverse selection of battery sizes and configurations to cater to a wide range of applications. Whether you need standard battery options or have unique power requirements, our team of experienced engineers is here to assist you throughout the entire process of designing, developing, testing, and manufacturing custom battery solutions tailored to your specific needs. Feel free to reach out to us today to learn more about our comprehensive range of battery solutions and how we can create a customized solution for you.
