ODM Deep Cycle Lithium Golf Battery 60V 200Ah Lithium Battery For Golf Trolley
Product Description
Deep cycle 60V 200Ah lithium battery pack for golf cart electric forflift
Battery Features:
The 60.8V 200Ah golf cart battery is a high-performance power solution for golf carts. With its compact dimensions of 997598181 mm and weighing 119 kg, this battery offers a combination of power and portability.
Featuring a voltage of 60.8V, it delivers a sufficient amount of power to drive the golf cart smoothly and efficiently. The high capacity of 200Ah ensures long-lasting operation, allowing golfers to enjoy extended periods of use before recharging is required.
The battery is specifically designed for golf cart applications, offering durability and reliability. Its robust construction can withstand the demands of the golf course, ensuring consistent power output and optimal performance.
With this battery, golfers can experience enhanced performance and reliability during their rounds. Its compact size and manageable weight make it easy to install and handle. The 60.8V 200Ah golf cart battery is a reliable and efficient power source that can keep golfers on the move on the green.
| Items | Specification |
|---|---|
| Cell Type | LiFePO4 (Customizable: LiFePO4 / NCM / Prismatic / Cylindrical) |
| Nominal Voltage | 60.8V |
| Battery Capacity | 200Ah |
| Nominal Energy | 12.16kWh (12160Wh) |
| Dimension [L*W*H] | 997*598*181 mm (39.25*23.54*7.12 inch) (Customizable Dimension) |
| Weight | ≈119kg (262.35 lbs) |
| Working Voltage | 47.5V~69.3V |
| Maximum Charge Current | 50A Continuous |
| Maximum Discharge Current | 150A Continuous |
| Battery Discharge Peak Current | 300A (3S) |
| Fast Charging | Supports Fast Charging |
| Cooling System | Air Cooling |
| Charging Temperature | 0~60°C (32℉~140℉) |
| Discharging Temperature | -20~65°C (-4℉~149℉) |
| Operating Humidity Range | <75% |
| Cycle Life (25°C / 77℉@60% DOD) | >8000 Cycles |
| Cycle Life (25°C / 77℉@80% DOD) | >6000 Cycles |
| Self-Discharge Rate | <3% per month (25°C / 77℉) |
| IP Grade | IP65 (Higher grade optional) |
| Monitoring & Protection | Smart BMS: Overcharge / OverDischarge / Overcurrent / OverTemperature / ShortCircuit |
| Optional Functions | Bluetooth / WiFi / Communication (RS485, CAN, etc) / Heating / Active Balance / Switch / LCD Screen / LED Touch Screen / APP |
| Optional Accessories | Charger, Parallel Cable, Communication Cable, Grounding Wire, etc. |
| Design Life | 10 Years |
| Warranty | 3 Years |
| User Manual | With the Battery Packaging |
| Certification & Safety Standard | UL / FCC / CE / IEC / RoHS / UN38.3 / MSDS |
Why choose us as your supplier and partner?
Competitive pricing with low minimum order quantities
Ability to provide samples quickly and support dropshipping
Streamlined shipping/customs process and delivery terms
Strong customer service and technical support
Customization capabilities for private labeling, packaging, product features
Experience supporting full solar energy systems and projects
CUSTOM BATTERY SOLUTIONS
Redway Battery specializes in providing a diverse selection of battery sizes and configurations to cater to a wide range of applications. Whether you need standard battery options or have unique power requirements, our team of experienced engineers is here to assist you throughout the entire process of designing, developing, testing, and manufacturing custom battery solutions tailored to your specific needs. Feel free to reach out to us today to learn more about our comprehensive range of battery solutions and how we can create a customized solution for you.
