TTN-SP Series 1800w 3000w 3800w 6200w 24v 48v High Frequency Solar Inverter Pure Sine Wave Inverter 80A/110A MPPT Solar Charge

Name: TTN-SP Series 1800w 3000w 3800w 6200w 24v 48v High Frequency Solar Inverter Pure Sine Wave Inverter 80A/110A MPPT Solar Charge
Brand: TTN New Energy Technology (Wenzhou) Co., Ltd

Price Negotiable

Price: $130.00/pieces >=30 pieces

MOQ: 30 pieces

Delivery Time: Negotiable

Brand: TTNergy

Product Description

Products Description

TTN Solar Inverter

An on-grid inverter’s main job is to convert DC power generated from the PV array into usable AC power. Hybrid inverters go a step further and work with batteries to store excess power as well. In the developing world, hybrid inverters are more of a necessity to compensate for weak or intermittent grids or a lack of grid electricity all together.

The Grid-interactive inverter consists of several hardware elements. The Grid-interactive inverter controls and monitors the connection of the electricity from the power plants. In addition, it also controls the disconnection of excess power from the plants. It ensures the dispatch of power at the peak time based on demand.

TTN-SP 1800W 3000W 3800W 6200W

Higher yields / Safe & Reliable / Smart / User-friendly

This is a multi-function inverter/charger, combining functions of inverter, solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.

Pure sine wave inverter
Programmable supply priority for PV , battery or Grid
High PV input voltage range(55~450VDC)
Built-in Max 110A(3.6KW&6.2KW) MPPT solar charge
Compatibe with lithium-ion battery
Support BMS communication with Lithium battery
Smart battery charge design to optimize battery life
Overload,high temperature,inverter output short circuit protection
Cold start function
Intelligent fan speed adjustment
Built-in anti-dusk kit for harsh enviromen(optional)
WIFI&GPRS available for IOS and android

MODEL	SP-2200	SP-3200	SP-4200	SP-7000
Rated Power	2200VA/1800W	3200VA/3000W	4200VA/3800W	7000VA/6200W
INPUT
Voltage	230VAC
Selectable Voltage Range	170-280VAC(for personal computers) 90-280VAC(for home appliances)
Frequency Range	50Hz/60Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt.Mode)	230VAC±5%
Surge power	4400VA	6400VA	8000VA	14000VA
Transfer Time	10ms (for personal computers) 20ms (for home appliances)
Wave form	Pure Sine Wave
BATTERY & AC CHARGER
Battery Voltage	12VDC	24VDC	24VDC	48VDC
Floating Charge Voltage	13.5VDC	27VDC	27VDC	54VDC
Overcharge Protection	15.5VDC	31VDC	31VDC	61VDC
Maximum charge current	60A			80A
SOLAR CHARGER
MAX.PV Array Power	2000W	3000W	5000W	6000W
MPPT Range@ Operating Voltage	55-450VDC
Maximum PV Array Open Circuit Voltage	450VDC
Maximum Charging Current	80A			110A
Maximum Efficiency	98%
PHYSICAL
*Dimension.DWH(mm)*	40528698mm			423290100mm	423310120mm
Net Weight (kgs)	4.5kg	5.0kg	7.0kg	8.0kg
Communication Interface	RS232/RS485(Standard) GPRS/WIFI(Optional)
OPERATING ENVIRONMENT
Humidity	5% to 95% Relative Humidity(No-condensing)
Operating Temperature	-10℃ to 55℃
Storage Temperature	-15℃ to 60℃

Note:

How to correctly match the battery capacity of the system is determined according to the specific usage requirements of the load and application scenarios, otherwise it will easily lead to insufficient battery capacity or excessive waste of power generation.
For details, please refer to the manual recommendation or consult online customer service.
