3.6KW/6.2KW Off Grid Solar Inverter Dual Output AC Output Voltage 120VA
Price:
$461.70/pieces 1-49 pieces
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
TTNergy
Product Description
Products Description
TTN Hybrid Inverter
The Grid-interactive inverter consists of several hardware elements. The Grid-interactive inverter controls and monitors the connection of the electricity from the power plants. In addition, it also controls the disconnection of excess power from the plants. It ensures the dispatch of power at the peak time based on demand.
TTN-ECO 3.6KW / 6.2KW
Higher yields / Safe & Reliable / Smart / User-friendly
This is a multi-function inverter/charger, combining functions of inverter, solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.
Output power factor 1.0
WIFI&GPRS available forlOS and AndroidInverter can run without battery
One-key restoration to factory Settings
Built-in Lithium battery automatic activation
Built-in 120AMPPT Solar charge:max 4200W(for 3.6KW)max 6000W(for 5KW)
AC output voltage 120VAC
High PV input voltage range(60- 500VDC)
Built-in anti-dust kit for harsh environment
Smart battery charge design to optimize battery life
Dual output
Note:
How to correctly match the battery capacity of the system is determined according to the specific usage requirements of the load and application scenarios, otherwise it will easily lead to insufficient battery capacity or excessive waste of power generation.
For details, please refer to the manual recommendation or consult online customer service.
For details, please refer to the manual recommendation or consult online customer service.
|
MODEL
|
TTN-ECO-LV-3.6KW PLUS
|
TTN-ECO-LV-6.2KW PLUS
|
||
|
Phase
|
1-Phase
|
|
||
|
Maximum PV Input Power
|
4200W
|
6000W
|
||
|
Rated Output Power
|
3600W(3000/3150/3300)
|
5000W(4100/4300/4500)
|
||
|
Maximum Solar Charging Current
|
120A
|
100A
|
||
|
GRID-TIE OPERATION
|
|
|
||
|
PV Input(DC)
|
|
|
||
|
Nominal DC Voltage/Maximum DC Voltage
|
360VDC/90VDC
|
|
||
|
Start-up Voltage/Initial Feeding Voltage
|
60VDC/90VDC
|
|
||
|
MPPT Voltage Range
|
60~450VDC
|
|
||
|
Number of MPPT Trackers/Max Input Current
|
1/23A
|
|
||
|
GRID OUTPUT(AC)
|
|
|
||
|
Norminal Output Voltage
|
120VAC(100/105/110V settable)
|
|
||
|
Output Valtage Range
|
60-150VAC
|
|
||
|
Norminal Output Current
|
30A
|
41.7A
|
||
|
Power Factor
|
>0.99
|
|
||
|
Feed-in Grid Frequency Range
|
47 55±0.3HZ/57~65±0.3HZ
|
|
||
|
EFFICIENCY
|
|
|
||
|
Max Conversion Efficiency(Solar to AC)
|
98%
|
|
||
|
TWO LOAD OUTPUT POWER(V2.0)
|
|
|
||
|
Full Load
|
3600W
|
6200W
|
||
|
Maximum Main Load
|
3600W
|
6200W
|
||
|
Max Second Load(battery mode)
|
1200W
|
2067W
|
||
|
Main Load Cut Off Voltage
|
22VDC
|
44VDC
|
||
|
Main Load Return Voltage
|
26VDC
|
52VDC
|
||
|
OFF-GRID OPERATION
|
|
|
||
|
AC Input
|
|
|
||
|
Rated Input Voltage
|
110/120VAC
|
|
||
|
Input Voltage Range
|
90~140VAC±2%
|
|
||
|
Maximum AC Input Current
|
30A
|
40A
|
||
|
Nominal operating frequency
|
47 55±0.3HZ/57~65±0.3HZ
|
|
||
|
Surge power
|
7200W
|
10000W
|
||
|
BATTERY MODE OUTPUT(AC)
|
|
|
||
|
Nominal Output Voltage
|
120VAC(100/105/110V settable)
|
|
||
|
Output Waveform
|
pure sine wave
|
|
||
|
Efficiency(DC to AC)
|
94%
|
|
||
|
BATTERY&CHARGER
|
|
|
||
|
Nominal DC Voltage
|
24VDC
|
48VDC
|
||
|
Maximum Solar Charging Current
|
120A
|
|
||
|
Maximum AC Charging Current
|
80A
|
|
||
