China Made in China Pure Sine Wave 1000W Inverter with Solar Charge for sale

Made in China Pure Sine Wave 1000W Inverter with Solar Charge

Name: Made in China Pure Sine Wave 1000W Inverter with Solar Charge
Brand: TTN New Energy Technology (Wenzhou) Co., Ltd

Price Negotiable

Price: $38.00/pieces 1-9 pieces

MOQ: Negotiable

Delivery Time: Negotiable

Brand: TTN

Product Description

Products Description

TTN Pure Sine Wave Inverter

TTN-SPGE 300W / 500W / 600W / 1000W / 1500W / 2000W

2500W / 3000W / 3500W / 4000W / 5000W / 6000W / 8000W

Introduction of power inverter:
1. This inverter power supply adopts SPWM technology controlled by MCU micro-processing, pure sine wave output, and the waveform is indeed pure. The unique dynamic current loop control technology ensures reliable operation of the inverter.
2. Load adaptability, including inductive load, capacitive load, resistive load, Hybrid load. High performance at over-load capacity and impact resistance.
3. It has perfect protection functions such as input over voltage, under-voltage, overload, overheat, and output short circuit
etc.
4. The sine wave inverter adopts LCD liquid crystal display mode, and the state is clear at a glance.
5. Stable performance, safe and reliable, long service life.

Model

300W-

12/24/48V

500W-

12/24/48V

600W-

12/24/48V

1000W-

12/24/48V

1500W-

12/24/48V

2000W-

12/24/48V

2500W-

12/24/48V

3000W-

12/24/48V

3500W-

12/24/48V

4000W-

12/24/48V

5000W-

12/24/48V

6000W-

12/24/48V

8000W-

24/48/96V

Digital display

300W/500W/8000W No display 600W/1000W/1500W/2000W/2500W/3000W/3500W/4000W/5000W/6000W LED display

Rated Power

300W~8000W

Surge Power

600W~16000W(few seconds)

Input Voltage

12VDC/24VDC/48VDC/96VDC

Output Voltage

110VAC±5%/220VAC±5%

USB Port

5V1A

Frequency

50Hz±3 or 60Hz±3

Output Waveform

Pure Sine Wave

Soft Start

YES

AC Regulation

THD<3%(Linear Load)

Output Efficiency

94% MAX

No Load Current

0.1A~3.8A

Cooling Way

Intelligent Cooling Fan

Protection

Battery Low Voltage & Over Voltage, Over Load, Over Temperature, Short Circuit. Reverse Polarity

Working Temperature

-10℃ - +50℃

Warranty

2 Years

Voltage Range	12V	24V	48V	96V
DC Voltage Range	10-15.5V	20-31V	40-61V	80~120V
Low Voltage Alarm	10.5±0.5V	21±0.5V	42±1V	83±1V
Low Voltage Shut Down	10±0.5V	20±0.5V	40±1V	80±1V
Low Voltage Recovery	13±0.5V	24±0.5V	48±1V	96±1V
Over Voltage Shut Down	15.5±0.5V	31±0.5V	61±1V	120±1V
Over Voltage Recovery	14.8V±0.5V	29V±0.5V	59V±1V	96±1V

Model	300W	500W	1000W	1500W	2000W	2500W
Net Dimension	19.511.26cm	23.2157.8cm	32.616.58.7cm	36.216.58.7cm	4316.58.7cm	441710.5cm
Inner Box Dimension	25.6159.8cm	28.620.313cm	35.120.512.2cm	45.620.612.2cm	45.620.612.2cm	noll
Meas/Ctn	51x49x30.7cm/18pcs	633438.5cm/10pcs	67.537.329.7cm/6pcs	5247.538cm/4pcs	5247.538cm/4pcs	51.523.317.5cm/4pcs
N.W/Unit	1.0kg (1.2kg With Inner Box)	2.0kg (2.3kg With Inner Box)	3.1kg(3.5kg With Inner Box)	4.3kg(4.8kg With Inner Box)	5.2kg(5.7kg With Inner Box)	4.76kg(4.76kg With Inner Box)
G.W/Ctn	23KGS	24KGS	22KGS	20KGS	24.5KGS	22.52KGS
Packing	Colour box	Colour box	Colour box	Colour box	Colour box	Colour box
Model	3000W	3500W	4000W	5000W	6000W	8000W
Net Dimension	46218.6cm(L×WxH)	442015 cm(L×WxH)	46.521.615.6cm(LxWxH)	46.521.615.6cm(LxWxH)	51.82014.5cm(LxWxH)	663023.5cm(LxWxH)
Meas/Ctn	53.551.527.5cm/4pcs	56.530.824cm/1pcs	57.531.525cm/1pcs	57.531.525cm/1pcs	64.33023.5cm/1pcs	743023.5cm/1pcs
N.W/Unit	26kg	8.92kg	10kg	10.5kg	12kg	14kg
G.W/Ctn	28KGS	10.7KGS	12KGS	12.5KGS	14KGS	18KGS
Packing	Carton	Carton	Honeycomb carton	Honeycomb carton	Honeycomb carton	Honeycomb carton
