60mm*180 Impeller AC Cross Blower Fan 40W 0.65A 115VAC 60HZ
60mm*180 Impeller AC Cross Blower Fan 40W 0.65A 115VAC 60HZ
The fan blower has a diameter of 60mm and operates with a power input of 40W and a current of 0.65A. It is suitable for cooling small to medium-sized equipment or systems. High air volume and wide air delivery, low-pressure laminar design which allows for efficient cooling and airflow distribution and low noise.
Quick Review:
|
Model Type: MH6029-29008 Motor Type:AC Shade Pole Motor |
|||
| Rated Voltage/Frequency | 115Vac/60Hz | Hi-Pot TEST | 1500vac50hz,1Ma,1s |
| Current(A) | 0.65 | Bearing Type | NMB Ball Bearing |
| Input Power(W) | 40 | Insulation Class | H (Thermally Protected) |
| Speed(RPM) | 1550 | Agency Certification | ETL |
| Wind Speed(m/s) | 8 | Air Volume(CFM) | 102 |
| Protected | TP | Start Voltage | 70V 60HZ |
Production Feature :
1. 60mm diameter *180mm impeller provides high airflow and low noise.
2. It is suitable for various applications, including food heating and cooling.
3. Driven by a C-FRAME shaded pole motor.
4. The motor can be mounted in any of 4 positions.
5. Equipped with ball bearings, suitable for high-temperature environments and long service life.
6. Multiple performance options are available.
The typical appilication:
Pellet Stove, OVEN, Lab Equipment
Shanghai MH Electric Co., Ltd, located in SHANGHAI, has been specialized in the field of exporting Shade Pole Motors & blowers for several years. We have our own production facility and a strong R&D team.
FAQ
Q1- What is the warranty of the motors?
The warranty is 18 months from the shipping date.
Q2- Can you design and make the motor as required?
Yes, we provide both ODM and OEM products.
Q3- What is your advantage?
Besides the good quality and the competitive price, we offer the short lead time and quick response.
Q4- What is your terms of payment?
T/T 30% as deposit, and 70% before delivery. The term can be negotiated for long-term business.
Q5- How to get the accurate quotation?
The accurate price will be quoted after the specification and mounting dimension of the motor are checked.
Q6- Do you test all products before the delivery?
Yes, all products are tested OK before the delivery
Q7- Do you have any MOQ for motors?
Usually our MOQ is one pallet. But we accept the small quantity for the trial order.
Q8- Do you have other products?
Yes, besides the shade pole motors and blowers ,we also offer OEM production for some industrial motors such as single phase AC motor, 3 phase industrial motor, stainless steel motor, BLDC fan motor etc... And we offer the sourcing service for other products required.
