Electric Stacker Forklift 1000kg
Product Description:
WDG10/12QL is a high performance electric counterbalance forklift truck. It is designed for indoor and outdoor applications in medium-sized warehouses and depots. With a maximum load capacity of 1,000kg, a lead acid battery of 24V-85Ah/120Ah, and a lowered mast height of 2080/1840/2090/2340mm, the WDG10/12QL has exceptional ground clearance of 30mm and a service weight of 553kg with battery. This truck offers a wide range of features to make your lifting operations easier and faster, including a lift height of 1600mm and a smooth, efficient operation. The WDG10/12QL is perfect for efficient and safe material handling in any environment.
Features:
- 1) Low voltage protection system to extend battery life;
- 2) Using adjustable balance wheel, the car walks smoothly;
- 3) The whole vehicle is small, flexible, and has good maneuverability, and can work efficiently in places with narrow spaces;
- 4) It has good shock absorption effect, and the balance wheel assembly can be disassembled as a whole, which is convenient for maintenance and warranty.
Technical Parameters:
| Model | WDG10QL |
| Load capacity | 1000kg |
| Tyre size, front | φ80×70 |
| Tyre size, rear | φ210×70 |
| Lift height | 1600/2500/3000/3500mm |
| Lowered height | 90mm |
| Overall length | 1750mm |
| Fork dimensions | 1070×142×60mm |
| Distance between fork arms | 550/660mm |
| Turning radius | 1437mm |
| Groung clearance | 30mm |
| Travel speed | 3.5/4 km/h |
| Gradient,Laden/unladen | 3/10% |
| Drive motor | 0.6kw |
| Lift motor | 2kw |
| Battery | lead-acid 24V 65Ah |
Applications:
AIDA WDG10/12QL is the perfect solution for any application where a heavy-duty industrial electric forklift is required. It features a maximum speed of 6 km/h, a turning radius of 1400 mm, a maximum gradient of 3%/10%, a service weight of 553 kg with a lead-acid battery, and an overall width of 790 mm. The width over forks is 550/660 mm, and the minimum order quantity is 1. This product is CE certified and is available at a negotiable price, with delivery time of 10-15 days. Payment terms are available in TT.
Support and Services:
We provide a range of technical support and service options for the WDG10/12QL product.
- Online support – Our website offers a range of product guides, FAQs and troubleshooting advice.
- Phone support – Our technical support team is available via phone to answer any questions you may have about the product.
- On-site support – We can provide on-site technicians to help you with installation, setup and maintenance of the WDG10/12QL product.
- Software updates – We will provide regular software updates to ensure your product is always up to date.
- Warranty – We offer a one-year warranty on all WDG10/12QL products.
Packing and Shipping:
The WDG10/12QL is securely packaged in a cardboard box to ensure it is not damaged during shipping. The box also includes foam inserts for extra protection. The product is then shipped via a reliable carrier to ensure it arrives on time and in good condition.
FAQ:
A1: The Brand Name of AIDA WDG10/12QL is AIDA.
A2: The Model Number of AIDA WDG10/12QL is WDG10/12QL.
A3: AIDA WDG10/12QL is from China.
A4: The Certification of AIDA WDG10/12QL is CE.
A5: The Minimum Order Quantity of AIDA WDG10/12QL is 1.
A6: The Price of AIDA WDG10/12QL is Negotiated.
A7: It takes 10-15days to deliver AIDA WDG10/12QL.
A8: The Payment Term is TT.
