AGV Industrial Servo Motor Driving Unit 2200N
AGV Driving Unit for Enhanced Efficiency Max Radial Force 2200N
Product Description:
The AGV Drive Unit is a reliable and powerful driving unit that is designed to meet the needs of medium to large-scale industrial applications. It features two wheel motors that provide a maximum radial force of 2200N and a maximum axial force of 1600N. The rated power of 2000W ensures that the unit can handle more demanding tasks. The encoder is an absolute value type, providing precise positioning for the unit. Additionally, the unit does not have a brake, allowing for a smooth and efficient operation.
Features:
1.Servo motors offer rapid response and dynamic control, which is useful in applications like robotics and CNC machining. When paired with a planetary reducer, the system can maintain high precision even at high speeds.
2.Demonstrating effective functionality across a wide range of temperatures, making it suitable for use in various industrial environments with fluctuating climate conditions.
3. Specially crafted for a rapid and straightforward installation process, which reduces downtime and simplifies maintenance procedures.
Planetary Gearbox Parameters:
| Model | Unit | Stages | Ratios | Nominal torquet Tn | Maxiumum efficengy |
| HKTLF115A | NM | 1 | 3 | 155 | 94% |
| 4 | 230 | ||||
| 5 | 245 | ||||
| 7 | 165 | ||||
| 10 | 95 |
Servo Motor Parameters:
|
Rated Torque |
6.73Nm |
|---|---|
|
Encoder |
Absolute Value |
|
Rated Current |
50A |
|
Rated Power |
2000W |
|
Rated Speed |
3000rpm |
|
Brake |
No Brake |
|
Supply Voltage |
DC 48V |
|
Number of Pole Pairs |
5 Poles |
|
Flange Size |
130*130mm |
