Compact AGV Drive Unit 2100N BLDC Servo Motor
Efficient AGV Drive Unit with 2100N Max Axial Force Compact Design
Product Description:
The AGV Drive Unit is an ideal solution for the automation of industrial and commercial processes. It is equipped with a powerful gearbox and wheel motors, and is designed to drive AGV systems. This unit is capable of delivering a maximum axial force of 2100N and a maximum radial force of 2600N, and is rated with a power of 2000W. The AGV Drive Unit is also provided with a flange of 130*130mm, without brake. It is an efficient and reliable driving system for different kinds of AGV systems.
Features:
1.These products are purposefully designed for seamless integration with the control systems of AGVs, guaranteeing smooth communication and coordination among the motor, reducer, and the vehicle's navigation system.
2.These precision reducers are intentionally designed to smoothly incorporate with AGV control systems, facilitating seamless communication and precise synchronization between the motor, reducer, and the vehicle's navigation system.
Planetary Gearbox Parameters:
| Model | Unit | Stages | Ratios | Nominal torquet Tn | Maxiumum efficengy |
| HKTLF115A | NM | 2 | 9 | 185 | 92% |
| 12 | 275 | ||||
| 16 | 275 | ||||
| 20 | 275 | ||||
| 25 | 290 | ||||
| 28 | 275 | ||||
| 35 | 290 | ||||
| 40 | 275 | ||||
| 50 | 290 | ||||
| 70 | 195 |
Servo Motor Parameters:
| Parameter | Details |
| Brake | With Brake |
| Max Axial Force | 2100N |
| Rated Power | 2000W |
| Max Radial Force | 2600N |
| Flange | 130*130mm |
| Encoder | Absolute Value |
| Rated Torque /Nm | 6.73 |
| Rated Current /A | 50 |
| Rated Speed/rpm | 3000 |
