EHV Power Cable UL83 Certificated Cu/PVC Thw Tw Thhn Wire Polyvinyl Chloride
Product Description
UL83 Certificated 14AWG 12AWG 10AWG CU/PVC THW TW Wire
1. Application:
General purpose building wire for services, feeders and branch circuits.
Temperature rating not to exceed:
THW: 75 °C wet or in oil, 600V
2. Construction:
Conductor: Annealed Copper, solid or stranded sizes 14AWG up to 1000MCM
Insulation: Premium Grade Flame Retardant Polyvinyl Chloride( PVC)
3. Standard&Test Specification:
THW Conforms to following standards:
UL83 for Thermoplastic Insulated Wire and Cables(THW)
UL758 for Appliance Wiring Materials(AWM)
UL1063 for Machine Tool Wire(MTW)(Stranded Conductor Only).
| Conductor | Insulation Thickness mil |
Nominal O.D. mils | Approx. Weight per 1000' (lbs.) |
Allowable Ampacities |
|
| Size AWG or kcmil |
Number of Strands |
75°C | |||
| 14 | 7 | 30 | 131 | 18 | 20 |
| 12 | 7 | 30 | 149 | 26 | 25 |
| 10 | 7 | 30 | 173 | 39 | 35 |
| 8 | 7 | 45 | 232 | 66 | 50 |
| 6 | 7 | 60 | 298 | 105 | 65 |
| 4 | 7 | 60 | 345 | 158 | 85 |
| 3 | 7 | 60 | 372 | 193 | 100 |
| 2 | 2 | 60 | 403 | 237 | 115 |
| 1 | 19 | 80 | 482 | 311 | 130 |
| 1/0 | 19 | 80 | 522 | 383 | 150 |
| 2/0 | 19 | 80 | 566 | 471 | 175 |
| 3/0 | 19 | 80 | 617 | 582 | 200 |
| 4/0 | 19 | 80 | 672 | 719 | 230 |
| 250 | 37 | 95 | 749 | 865 | 255 |
| 300 | 37 | 95 | 800 | 1021 | 285 |
| 350 | 37 | 95 | 851 | 1177 | 310 |
| 400 | 37 | 95 | 895 | 1337 | 335 |
| 500 | 37 | 95 | 977 | 1645 | 380 |
| 600 | 61 | 95 | 1086 | 1990 | 420 |
| 750 | 61 | 110 | 1189 | 2457 | 475 |
| 1000 | 61 | 110 | 1338 | 3232 | 545 |
