Low Voltage Power Cable Earth Wire 1c PVC V-90 Insulation Cable
Product Description
Application: Fire Resistant - Mains and Sub-Mains, Fire Alarm Systems, Essential Services
Construction:
1. Conductor - Plain annealed class 2 /5 flexible copper
2. Fire Resistant layer - Mica Tape
3. Insulation - Cross-linked low-smoke halogen-free polyolefin compound (X-HF-110)
4. Outer sheath - Cross-linked low-smoke halogen-free polyolefin compound (HFS-110-TP)
Cross Section:
1 core: 1.5~630mm2
Temperature characteristics:
Conductor operating temperature: -40ºC~110ºC
Min. temperatrue laying condition: 0ºC
Electrical Characteristics:
Rated voltage: 0.6/1 (1.2) kV
High voltage test: 3.5kV / 5min
Color:
Insulation: White or according to customer requirements
Sheath: Red or according to customer requirements
Standard:
Cable design: AS/NZS5000.1
Conductor: AS/NZS 1125
Fire resistant : AS/NZS3013 (WS52W)
| Cond. Area mm |
Stranding No/mm |
Insulation Thick mm |
Sheath Thick mm |
Nom.O/D mm |
Min. Installed Bending Radius mm |
Approx. Mass Kg/Km |
Order Now |
| 1 | 1x1/1.13 | 0.6 | 0.8 | 4.1 | 20 | 30 | |
| 1.5 | 1x7/0.50 | 0.6 | 0.8 | 4.5 | 20 | 40 | |
| 2.5 | 1x7/0.67 | 0.7 | 0.8 | 5.2 | 25 | 55 | |
| 4 | 1x7/0.85 | 0.8 | 0.9 | 6.2 | 25 | 80 | |
| 6 | 1x7/1.04 | 0.8 | 0.9 | 6.8 | 30 | 100 | |
| 10 | 1x7/1.35 | 1 | 0.9 | 8.2 | 35 | 145 | |
| 16 | 1x7/1.70 | 1 | 1 | 9.4 | 40 | 225 |
Other sizes can also be produced as you required.
| Size | Conductor Strands | Insulation Thickness |
| 2x1.5mm2 | 7/0.52mm | 0.6mm |
| 2x2.5mm2 | 7/0.68mm | 0.7mm |
| 2x1.5mm2+1.5mm2 | 7/0.52mm | 0.6mm |
| 2x2.5mm2+2.5mm2 | 7/0.68mm | 0.7mm |
| 2x4mm2+2.5mm2 | 7/0.85mm+7/0.68mm | 0.8mm |
| 2x6mm2+2.5mm2 | 7/1.04mm+7/0.68mm | 0.8m |
Fang Yu (Shanghai) Automation Technology Co., Ltd. Cable has passed ISO9001 quality management system certification, ISO14001 environmental management system certification, ISO45001 occupational health and safety management system certification, ISO50001 energy management system certification, and two integration management system certification. It has also received the title of national green factory.
Fang Yu (Shanghai) Automation Technology Co., Ltd. These include over 30 series of products, such as plastic-insulated power cables for land and submarine applications ranging from 500kV down to 0.5kV, rubber-insulated wires and cables ranging from 35kV down to 1kV, overhead insulated cables, overhead wires, mine cables, fire-resistant cables, high-temperature cables, extremely cold-resistant cables, cables for offshore engineering equipment, control cables, computer cables, photovoltaic cables, new energy vehicle cables, building wires, and network wires. In total, there are nearly 4,000 types and over 50,000 specifications.
