PC40-7 PC45 Excavator Swing Motor 708-7T-00122 708-7R-00190 Slew Motor
PC50UU-2 swing motor 708-7T-00122 708-7R-00190 slew motor for PC40-7 PC45 PC50UU
Product Descriptio
| Pos. | Part No | Qty | Parts name |
| 708-7T-00122 | [1] | SWING MOTOR ASSY Komatsu | |
| ["SN: 1101-UP"] analogs:["7087T00123", "R7087T00122"] |$0. | |||
| 1. | 708-7T-11211 | [1] | CASE Komatsu China |
| ["SN: 1101-UP"] | |||
| 2. | 708-7T-11612 | [1] | CAP,END Komatsu China |
| ["SN: 1101-UP"] | |||
| 3. | 708-7T-11120 | [1] | GASKET Komatsu China |
| ["SN: 1101-UP"] analogs:["890001153", "PZF890001153"] | |||
| 4. | 720-68-19610 | [3] | PIN Komatsu |
| ["SN: 1101-UP"] | |||
| 5. | 01010-31060 | [4] | BOLT Komatsu |
| ["SN: 1101-UP"] analogs:["01010E1060"] | |||
| 6. | 708-7T-12211 | [1] | SHAFT Komatsu |
| ["SN: 1101-UP"] | |||
| 7. | 708-7T-12240 | [1] | BEARING Komatsu China |
| ["SN: 1101-UP"] analogs:["890001364"] | |||
| 8. | 708-7T-12250 | [1] | BEARING Komatsu China |
| ["SN: 1101-UP"] analogs:["890001365"] | |||
| 9. | 708-7T-12230 | [1] | SEAL,OIL Komatsu |
| ["SN: 1101-UP"] | |||
| 10. | 04065-04518 | [1] | RING,SNAP Komatsu |
| ["SN: 1101-UP"] | |||
| 11. | 708-7T-05020 | [1] | SPACER KIT Komatsu |
| ["SN: 1101-UP"] | |||
| 12. | 708-7T-13421 | [1] | PLATE,THRUST Komatsu |
| ["SN: 1101-UP"] | |||
| 13. | 708-7T-13510 | [1] | GUIDE,RETAINER Komatsu China |
| ["SN: 1101-UP"] analogs:["890001157", "PZF890001157"] | |||
| 14. | 708-7T-13560 | [1] | SPRING Komatsu China |
| ["SN: 1101-UP"] | |||
| 15. | 708-7T-13530 | [2] | WASHER Komatsu China |
| ["SN: 1101-UP"] analogs:["890001158", "PZF890001158"] | |||
| 16. | 708-7T-13540 | [3] | PIN Komatsu China |
| ["SN: 1101-UP"] analogs:["890001159", "PZF890001159"] | |||
| 17. | 04065-03815 | [1] | RING,SNAP Komatsu |
| ["SN: 1101-UP"] | |||
| 18. | 708-7T-13611 | [7] | PISTON SUB ASSY Komatsu China |
| ["SN: 1101-UP"] | |||
| 19. | 708-7T-13342 | [1] | RETAINER,SHOE Komatsu China |
| ["SN: 1101-UP"] analogs:["890001163", "PZF890001163", "R7087T13342"] | |||
| 20. | 708-7T-13121 | [1] | BLOCK,CYLINDER Komatsu China |
| ["SN: 1101-UP"] analogs:["890001170", "890001376", "PZF890001170", "7087T13140", "7087T13120", "R7087T13121"] | |||
| 21. | 708-7T-13250 | [1] | PLATE,VALVE Komatsu |
| ["SN: 1101-UP"] | |||
| 22. | 708-7T-16110 | [2] | VALVE Komatsu China |
| ["SN: 1101-UP"] analogs:["890001165", "PZF890001165"] | |||
| 23. | 708-7T-16130 | [2] | SPRING Komatsu China |
| ["SN: 1101-UP"] | |||
| 24. | 07040-11812 | [2] | PLUG Komatsu |
| ["SN: 1101-UP"] analogs:["0704001812"] | |||
| 25. | 07002-11823 | [2] | O-RING Komatsu |
Theory
The SWING motor is a key component of the excavator's slewing mechanism. It converts the oil pressure provided by the main pump into mechanical energy and inputs it to the reducer. Its working performance will directly affect the rotation speed, driving torque, and rotation of the entire machine. Parking and parking brakes are key to determining the productivity of the entire machine. After the excavator has been working for a long time, the swing motor often appears weak in rotation and unstable in rotation. At this time, it is necessary to replace the internal parts based on the test results.
Advantages
Warehouse Display
