PC200-8 Excavator Hydraulic Pump Assy 708-2L-00500 708-2L-01500
PC200-8 HPV95 hydraulic pump assy 708-2L-00500 hydraulic main pump for Komatsu
Product Descriptio
| Pos. | Part No | Qty | Parts name | Comments |
| 708-2L-00500 | [1] | Pump Assembly Komatsu | 145 kg. | |
| ["SN: 350001-350614"] analogs:["7082L00501", "7082L00400", "7082L00490"] |$0. | ||||
| 708-2L-01500 | [1] | Pump Subassembly Komatsu China | ||
| ["SN: 350001-350614"] |$1. | ||||
| 1 | 708-2L-32170 | [1] | Shaft,Rear Komatsu | 2.1 kg. |
| ["SN: 350001-350614", "SCC: C2"] | ||||
| 2 | 708-2L-32150 | [1] | Bearing Komatsu | 0.6 kg. |
| ["SN: 350001-350614", "SCC: C2"] analogs:["7082E12152", "7082L22150", "7082512731"] | ||||
| 3 | 708-2E-05040 | [1] | Washer Kit Komatsu | 0.101 kg. |
| ["SN: 350001-350614", "SCC: C2"] analogs:["7082E12190"] | ||||
| 4 | 708-25-12790 | [1] | Ring, Snap Komatsu | 0.006 kg. |
| ["SN: 350001-350614", "SCC: C2"] | ||||
| 708-2L-06480 | [1] | Block Assembly,Rear Komatsu | 5.26 kg. | |
| ["SN: 350001-350614", "SCC: C2"] |$10. | ||||
| 7 | 720-68-19610 | [1] | Pin Komatsu | 0.002 kg. |
| ["SN: 350001-350614", "SCC: C2"] | ||||
| 8 | 04065-04818 | [1] | Ring, Snap Komatsu OEM | 0.007 kg. |
| ["SN: 350001-350614", "SCC: C2"] | ||||
| 9 | 708-2L-23131 | [1] | Seat Komatsu | 0.073 kg. |
| ["SN: 350001-350614", "SCC: C2"] | ||||
| 10 | 708-2L-33160 | [1] | Spring Komatsu | 0.12 kg. |
| ["SN: 350001-350614", "SCC: C2"] analogs:["7082L23151"] | ||||
| 11 | 708-7L-13140 | [1] | Seat Komatsu | 0.02 kg. |
| ["SN: 350001-350614", "SCC: C2"] | ||||
| 12 | 708-2L-23351 | [1] | Guide, Retainer, Retainer Komatsu OEM | 0.14 kg. |
| ["SN: 350001-350614", "SCC: C2"] | ||||
| 13 | 708-2L-23360 | [3] | Pin Komatsu | 0.003 kg. |
| ["SN: 350001-350614", "SCC: C2"] | ||||
| 14 | 708-2L-33350 | [1] | Retainer, Shoe, Shoe Komatsu | 0.3 kg. |
| ["SN: 350001-350614", "SCC: C2"] | ||||
| 15 | 708-2L-33430 | [9] | Piston Subassembly Komatsu | 0.209 kg. |
| ["SN: 350001-350614", "SCC: C2"] | ||||
| 708-2L-06630 | [1] | Cradle Assembly Komatsu | 4.3 kg. | |
| ["SN: 350001-350614", "SCC: C2"] |$22. | ||||
| 18 | 04020-01228 | [1] | Pin, Dowel Komatsu | 0.026 kg. |
| ["SN: 350001-350614", "SCC: C2"] analogs:["21T3016190"] | ||||
| 19 | 01252-61230 | [4] | Bolt, Hexagon Socket Head Komatsu | 0.044 kg. |
| ["SN: 350001-350614", "SCC: C2"] |
About Xinfeng Machinery (XF) parts:
Advantages
Warehouse Display
Packaging and Delivery
FAQ
1. How to quickly and accurately buy products what lneeded?
A: Provide the original parts number to us to check.
2. How long have you been in the excavator
A: We are engaged in excavator parts since 1998
3. lfI don't know the part number,what shouldI do?
A: Please send us size and pictures of old products.
4. What is the warranty of the products?
A: The warranty is 6/12 Months based on the specific product.
5. How long is your delivery time?
A: The normal delivery time is 3-5 days for stock sproductsafter getting payment. lf not in stock, we will inform you thetime requlred.
6. Which shipping term you can supply?
A: By sea,air or by express ( DHL,Fedex,TNT,UPSEMS)
7. What is your MOQ?
A: Small order and sample order are acceptable
8. Do you have any After-Sales service?
A: Yes!Our
