100ah 200ah 5kw Lithium Ion Battery Pack 48V Lifepo4 Solar Energy System 10kw
Specific parameters
| Product Model | ESK-4810CW | ESK-4820CWP | ESK-4820CW |
| Type of Battery | Lithium Iron Phosphate | ||
| Max parallel | 16 sets | ||
| Rated capacity | 100AH (5120WH) | 184AH (9420.8WH) | 200AH (10240WH) |
| Rated voltage | 51.2V | ||
| Charging voltage | 58.4V | ||
| Max charging current | 100A | ||
| Max continuous discharge current | 100A/150A/200A optional | ||
| Weight | 47kg | 74kg | 85kg |
| Dimension (L* W * H) mm | 620*460*195 | 850*455*180 | 955*460*195 |
| Display | LCD | ||
| Warranty | 8 years | ||
| communication function | CAN/RS485/RS232 | ||
| Shell Material | White painted steel | ||
| Cycle life | ≥6000 times | ≥8000 times | ≥8000 times |
| Operating temperature | -20℃ to +65℃ | ||
| Protection function | Overcharge protection, over discharge protection, over-current protection, short circult protection, over temperature protection and low voltage alarm | ||
| Matched solar inverter brands | PYLONTECH/GOODWE/Growatt/SMA/Victron/TBB/Must/Srne/MEGAREVO/Deye/INVT/Voltronic/SOFAR/SOROTEC,etc. | ||
| Bluetooth function | Optional | ||
| Application | Home Appliances, Industrial and commercial energy storage,Household energy storage,Large-scale photovoltaic energy storage projects,UPS energy storage | ||
Lifepo4 Battery 100ah 200ah 5kw Lithium Ion Battery Pack 48v Solar Energy System 10kw
Grade A lifepo4 blade cell
＞8000 cycle life Grade A lifepo4 blade cell for higher and
safer temperature resistance.
Built-in intelligent BMS system
Intelligent BMS balancing module ensures the stability
and balance of all battery cells.
Matching all mainstream solar inverters
Our Service
● Samples Service
We can provide you with samples, which will be displayed by video or sent to you to confirm whether the energy storage products meet your requirements
● OEM/ODM Service
We can customize your exclusive energy storage products and system according to your needs, and display or provide them to you to confirm whether they meet your needs. If you can't determine the specific requirements, you can tell us your application scenario. We will match the products that meet your needs based on our rich experience and professional knowledge.If you have your own brand or trademark, you can authorize us to use it on your exclusive energy storage products.
● Pre-sales and after-sales Service
We have a professional pre-sales and after-sales team to serve you. The pre-sales team can ensure that we can accurately understand your needs, accurately convey your needs to the factory, and supervise the factory to accurately produce the products you need. The after-sales team can conduct installation teaching and use technical guidance after you receive the product, and can track and solve any problems for you in time when the product has any problems
● Professional team service
We have more than 10 senior engineers and more than 60 professional technicians who have been committed to product R & D for more than 18 years,And professional pre-sales and after-sales team has served you and received unanimous praise
● Source factory
All products are developed and produced by ourselves, with guaranteed quality and service and preferential prices.
Our Advantages:
R & D team
We have more than 10 senior engineers and more than 60 professional technicians who have been committed to product R & D for more than 18 years.
Quality control
Quality control is the basis of our management. We put it first. All products are strictly tested before leaving the factory.
OEM/ODM customization service
We can customize your exclusive energy storage products and system according to your needs, and display or provide them to you to confirm whether they meet your needs. If you can't determine the specific requirements, you can tell us your application scenario. We will match the products that meet your needs based on our rich experience and professional knowledge.If you have your own brand or trademark, you can authorize us to use it on your exclusive energy storage products.
Professional pre-sales and after-sales team
We have a professional pre-sales and after-sales team to serve you. The pre-sales team can ensure that we can accurately understand your needs, accurately convey your needs to the factory, and supervise the factory to accurately produce the products you need. The after-sales team can conduct installation teaching and use technical guidance after you receive the product, and can track and solve any problems for you in time when the product has any problems
