PVDF Pre Painted Galvanized Steel Coils With AkzoNobel Paint 3-5 Ton Coil Capacity
PVDF Pre-Painted Galvanized Steel Coils Beckers AkzoNobel
The color-coated steel sheets, galvanized sheets, color contour plates, color steel tiles, steel structure construction materials and other products have large varieties and complete specifications. The company is well facilitated with advanced equipment, and a strong technical force, carrying out multi-process strict quality control. We can produce color-coated steel sheets of 0.13mm-1.5mm × 600mm-1500mm and specifications.
Specifications
Name
PPGI/ PPGI Steel Coils/color pre-painted galvanized steel coils
Base material
hot-dip galvanized steel coil, galvalume steel coil
Material/Grade
SGCC, SGCH, SGCL, DX51D,DX52D,DX53D,DX54D,SPCC,SPHC
Technique
Hot Rolled
| Index | Pre-Painted Galvanized/ Galvalume / Aluminum Sheets & Coils |
| Thickness | Base Metal : GI: 0.20-1.70mm; GL: 0.20-1.50mm |
| Base Metal: Aluminum 0.30-3.0mm | |
| Width | 600~1500mm |
| Zinc Coating |
Z40~Z275 g/㎡ AZ30~AZ200 g/㎡ |
| Paint Structure | 2/1, 2/2, 3/2, 3/3 |
| Paint Coating |
Top side: 15μm~55μm Back side: 5μm~30μm |
| Paint System | RMP, PE, SMP, HDP, PVDF |
| Paint Brand |
PPG Beckers AkzoNobel Valspar (Sherwin-Williams) Chinese local brands |
| Paint surface |
Gloss RAL color system Textured/Matt/Wrinkle Surface Printch Pattern Colors-Wood, Brick, Stone grains. |
| Coil weight | 2 ~ 10 tons |
| Packing |
Standard export packing ( Eye to Side) Vertical Packing ( Eye to Sky) with wooden pallet Horizontal Packing ( Eye to Side) with wooden pallet |
| MOQ. | 25 tons/color/size |
