AZ70 Hot Dip Galvalume CR Full Hard Steel Coils For Corrugated Sheet Panels g550 grade
AZ70 Hot Dip Galvalume CR Full Hard Steel Coils For Corrugated Sheet Panels G550 Grade
The coating consists of 55% aluminum, 43.5% zinc, and 1.5% silicon in weight ratio, respectively.
The production process of aluminum zinc steel sheet is similar to that of galvanized steel plate and aluminum plated plate,
and it is a continuous melting coating process.
55% aluminum zinc alloy coated aluminum zinc steel plate has superior corrosion resistance
ompared to galvanized steel plate of the same thickness when exposed to the same environment on both sides.
55% aluminum zinc alloy coated aluminum zinc steel ( 55% Alu-zinc Steel) plate not only has good corrosion resistance,
but also color coated products have excellent adhesion and flexibility.
| Product Name | GL |
| Base Metal | CR Full hard steel coils |
| Standard | AISI, ASTM, BS, DIN, GB, JIS |
| Material | SGCC,SGCH,DX51D |
| Thickness | 0.13-2.5 mm |
| Width | 600-1300mm |
| Coil ID | 508/ 610 mm |
| Aluzinc Coating | AZ 30-150 (g/m2) |
| Hardness | Soft hard(HRB60), Medium hard(HRB60-85), full Hard(HRB85-95) |
| Surface Treatment | Anti-fingerprint,dry,oiled,chromated , |
| Coil weight | 3-10tons |
| Tolerance | 5-10% |
| Packing | kraft paper +plastic film+steel sheet +steel strips |
| MOQ | 25Tons (1* GP 20 FCL) |
| Capacity | 1,500,000.00 Ton / year |
| Trade Term | FOB,CFR,CIF |
| Payment Term | L/C or T/T(30% deposit) |
| Delivery Date | within 20-30 days after receiving the deposit |
| Loading Port | Tianjin port ,Qingdao Port or any port in China |
| Application | Roof, walls, garage, soundproof walls, plumbing home application,advatising,furniture industry,food storage |
