SS255 - SS550 BOBINAS DE ACERO GALVANIZADAS DE CERO GRIETAS CROMATO SIN AFP
SS255-SS550 Zero spangle Galvanized Steel Coil/Sheets Chromated free AFP (anti-finger print)
SS255 - SS550 BOBINAS DE ACERO GALVANIZADAS DE CERO GRIETAS CROMATO SIN AFP
Zero Spangle Galvanized Steel Coils/GI Steel The zinc protects the steel by providing cathodic protection to the exposed steel, so should the surface be damaged the zinc will corrode in preference to the steel Galvanised steel is one of the most widely used products, used extensively in the building sector, automotive, agricultural and other areas where the steel needs to be protected from corrosion
![]()
Galvanised steel is mild steel with a coating of zinc The zinc protects the steel by providing cathodic protection to the exposed steel, so should the surface be damaged the zinc will corrode in preference to the steel Galvanised steel is one of the most widely used products, used extensively in the building sector, automotive, agricultural and other areas where the steel needs to be protected from corrosion
Hot-Dip Galvanizing or HDG is a process in which zinc bonds to steel at the molecular level to produce a four-layer corrosion-resistant finish. The first three layers are zinc-iron alloy layers that are actually harder than the base steel. The fourth or top layer is pure zinc.
Applications of Our Galvanized Steel Coils :
1.Construction and building: roofing; ventilating duct; handrail; partition panel,etc.
2.Further processing: coating base plate.
3.Electric appliance: refrigerator; washing machine; recorder; microwave, etc.
1) Standard: JIS G3302 1998, ASTM A653M/A924M 2004, all according to the customer's request
2) Grade: SGCC, SGCH,DX51D, Q195,Q235 all according to the customer's request
3) Capacity: about 12000 tons per month
5) Width: from 600mm to 1250mm, regular size:750-762mm,900-914mm,1000mm,1200mm,1219-1250mm all available
6) Coil ID: 508mm
7) Coil weight: from 2-10MT, according to the customer's request
9) Spangle: regular spangle,big spangle, small spangle and zero spangle
10) Surface treatment: Chemical passivating, oils, passivating oils,skin passed
11) Edge: mill edge, cut edge
12) Min trial order 25 ton each thickness
Home Appliance Application:
| Index |
Regular spangle Galvanized Steel Coil/Sheets |
Zero spangle Galvanized Steel Coil/Sheets |
| Thickness | 0.13-2.50mm | 0.20-2.0mm |
| Width | 600~1500mm | 600~1500mm |
| Zinc Coating | Z30~Z400 g/㎡ | Z30~Z275 g/㎡ |
| Surface Treatment |
Passivated / Chromated 6+,3+, Free; Oiled |
Skin passed, Chromated 6+, 3+, Free Oiled, AFP (anti-finger print) |
| Steel Grade |
DX51D/52D/53D/ S250GD/280GD/350GD/550GD ASTM A653M, SS255-SS550 JIS G3302-SGCC, SGCH (Full hard-G550) |
DX51D/52D/53D/ S250GD/280GD/350GD/550GD ASTM A653M, SS255-SS550 JIS G3302-SGCC, SGCH (Full hard-G550) |
| Coil I.D. | 508 / 610 mm | 508 / 610 mm |
| Coil weight | 2 ~ 20 tons | 2 ~ 20 tons |
| Packaging |
Standard export packing ( Eye to Side) Vertical Packing ( Eye to Sky) with wooden pallet Horizontal Packing ( Eye to Side) with wooden pallet |
|
| MOQ. | 16 tons | 16 tons |
| Loading port | Tianjin / Qingdao / Rizhao port | |
| Usage | Purlins, light steel frame, ventilation duct, downpipe, round pipe, square pipe, roof panel, corrugated sheets. |
Coated steel coil production, household appliances ( pre-coated metal PCM) Roof panel, corrugated sheets |
| STEEL GRADE | CHEMICAL COMPOSITION % | MECHANIC PROPERTY |
C.B OF COATING |
COATING | ||||||
| C | Si | Mn | S | P | T.S | Y.S | E.L | |||
| x103 | x103 | x102 | x103 | x103 | Mpa | Mpa | % | d=0 180° | G/M² | |
| JIS G3302 SGCC | 12 | 30 | 41 | 31 | 21 | 480 | 300 | 13 | OK | Z60-150 |
| JIS G3302 SGCH | 12 | 10 | 21 | 18 | 8 | 680 | 650 | OK | Z60-150 | |
| ASTM A653 CS.B | 20 | 30 | 60 | 35 | 30 | 386 | 205~380 | 20 | OK | Z80-275 |
| DX51D+Z | 29 | 21 | 18 | 1.8 | 11 | 355 | 245 | 38 | OK | Z80-275 |
| G550 | 20 | 6 | 73 | 5 | 17 | 715 | 654 | 8 | OK | Z80-275 |
| Name | prime hot dipped galvanized steel coil |
| Standard | ASTM, AISI, DIN, GB |
| Grade |
SGCC,DC51D,DX51D,DX52D,,SGCD,Q195,Q235,SGHC,DX54D, S350 GD, S450 GD,S550 GD... |
| Thickness | 0.135mm-4.0mm |
| Width | 600mm-1500mm762mm,914mm,1000mm,1200mm,1219mm,1250mm |
| Zinc Coating |
30~275gsm 40g,60g, 80g, 90,100g, 120g, 140g,180g, 200g, 250g, 275g and so on. |
| Spangle | zero spangle, regular spangle or normal spangle |
|
Surface Treatment |
|
| Coil Weight | 3-8ton or as client requirement. |
| Quality |
soft or hard quality |
Construction Application:
