GL 0.95*168 0.75*188 AZ150 G550 Structural Steel Grade Light House Build AFP Galvalume Steel GL 55% Aluzinc Steel Coil

GL 0.95*168 0.75*188 AZ150 G550 Structural Steel Grade

Light House Build AFP Galvalume Steel GL 55% Aluzinc Steel Coil

Hot-dip aluminium-zinc coated steel plate is a pre-coated steel plate obtained by hot-dip plating a layer of Al-Zn coating on both sides of a cold rolled steel plate of various strengths and thicknesses as a substrate, with a mass percentage of 55% Al (aluminium), 43.5% Zn (zinc) and 1.5% Si (silicon) in the composition of the plated layer, which combines the physical protection of Al and high durability as well as the electrochemical protection of Zn, and has the strength and plasticity of the base steel, and the corrosion resistance of the coating. The material has the strength and plasticity of substrate steel and the corrosion resistance of plating, which protects the metal substrate from internal corrosion. In addition, the surface has a highly decorative bright silver grey colour and regular patterns with a sense of embossment.

Characteristics:

Corrosion Resistance: Zinc is highly chemically active, forming a thin, dense layer of alkaline zinc carbonate film on its surface at room temperature, which prevents further oxidation. Similarly, aluminum forms a layer of insoluble oxides in the air, providing effective barrier protection.

Heat Resistance: Aluminum-zinc plated sheets can withstand high temperatures up to 315 degrees Celsius, making them suitable for high-temperature environments.

Reflectivity: Aluminum-zinc coated sheets have high reflectivity, with a heat reflectivity nearly twice that of galvanized steel. This makes them ideal for use on steel metal roofs, contributing to energy savings.

Ease of Painting: Aluminum-zinc-plated sheets have excellent adhesion properties between the sheet and paint, allowing them to be painted without the need for pre-treatment or weathering.

1) Standard: ASTM A792M, AS1397, EN10346/ EN10143 all according to the customer's request
2) Grade: SGCC, CS-Type B, Grade 350, G550, Grade 50, Grade 80, SS550GD, all according to the customer's request

3) Capacity: about 20000 tons per month

4) Thickness: from 0.13mm to 2mm, all available
5) Width: from 600mm to 1250mm, regular size:750-762mm,900-914mm,1000mm,1200mm,1219-1250mm all available
6) Coil ID: 508mm
7) Coil weight: from 2-10MT, according to the customer's request

8) Zinc coating weight: AZ30~AZ165g/m2

9) Spangle: regular spangle,big spangle, small spangle
10) Surface treatment: Anti-finger print (Green, Blue, Golden, No color) Chemical passivating, oils, passivating oils,skin passed
11) Edge: mill edge, cut edge
12) Min trial order 25 ton each thickness

Application:

Export Package
