Portable Silent Diesel Generator Single Cylinder Air-cooled Diesel Generator 6kW / 6.5kW
Portable silent diesel generator single cylinder air-cooled diesel generator 6kW / 6.5kW
Product Description: 6KW Air-cooled Portable Silent Diesel Generator
Standard Features:
- Model: TDG8500L, a trusted and reliable power source.
- Output: Rated at 6kW (50Hz) or 6.5kW (60Hz), with a maximum output of 6.5kW (50Hz) or 7kW (60Hz).
- Voltage Options: Versatile AC voltage outputs to meet various needs, including 110V, 120V, 220V, and more.
- Frequency: Available in 50Hz or 60Hz to suit different electrical systems.
- Noise Level: Operates at a low noise level of 75-77dB, ideal for noise-sensitive environments.
Key Features:
- Portability: Easy to transport and deploy, making it suitable for remote locations or emergency backup power.
- Silent Operation: Features advanced silencing technology for quiet operation, minimizing noise pollution.
- Air-cooled Design: Efficient air-cooled diesel engine ensures reliable performance and durability.
- Versatile Output: Multiple voltage and phase options allow for use in a wide range of applications.
6kW Portable Silent Diesel Generator Air-cooled Specifications:
| 6KW Air-cooled Portable Silent Diesel Generator Specifications | |||
| GENERATOR | Model | TDG8500L | |
| Frequency(Hz) | 50 | 60 | |
| Rated output (kW) | 6 | 6.5 | |
| Max output (kW) | 6.5 | 7 | |
| Rated AC voltage(V) | 110,120,220,230,127/220,120/240,220/380,230/400 | ||
| Power factor(cosΦ) | 1/0.8 | ||
| DC output(V/A) | 12/8.3 | ||
| Phase | Single OR Three | ||
| Alternator type | Self-excited | ||
| Starting system | Recoil type hand starting | ||
| Noise level(at 7m)(dB) | 75-77 | ||
| Fuel tank capacity(L) | 15 | ||
| electrical machinery(D*L) | 190*160 | ||
| ENGINE | Model | 192FDE | |
| Engine type | Single-Cylinder,Vertical 4-Cycle,Air-cooled diesel | ||
| Bore*stroke(mm) | 92*75 | ||
| Displacement capacity(CC) | 498 | ||
| Fuel | 0# or-10# light diesel oil | ||
| Lubrication oil volume(L) | 1.65 | ||
| Combustion system | Direct injection | ||
| DIMENSIONS | PACKING Dimension(L*W*H)(mm) | 930*540*780 | |
| Gross weight(KG) | 150 | ||
| 20FT | 72 | ||
| 40HQ | 150 | ||
Usage:
The 6KW air-cooled portable silent diesel generator is ideal for use in a variety of settings, including:
- Emergency backup power for homes, hospitals, and other critical facilities.
- Remote locations where traditional power sources are unavailable or unreliable.
- Construction sites, outdoor events, and other temporary power needs.
Advantages:
- Efficient & Reliable: The air-cooled diesel engine provides efficient and reliable power output, ensuring continuous operation.
- Cost-Effective: With its fuel-efficient design, the generator offers long run times with minimal fuel consumption.
- Easy to Maintain: Simple maintenance requirements and easy access to components make upkeep a breeze.
- Environmentally Friendly: Low emissions and quiet operation contribute to a greener, more sustainable power solution.
Options:
- Choose between single or three-phase configurations to suit your specific power needs.
- Customize your generator with optional accessories, such as additional fuel tanks or covers.
FAQ:
Q: How loud is the generator?
A: The generator operates at a low noise level of 75-77dB, making it suitable for use in noise-sensitive environments.
Q: How long can the generator run on a full tank of fuel?
A: The fuel tank capacity of 15 liters allows for extended operation, but run time will depend on the load and other factors.
Q: Is the generator easy to transport?
A: Yes, its portable design and compact size make it easy to transport and deploy wherever needed.
