CKD Type 13kVA Generator Yanmar Diesel Generator With 50C Radiator Couple With Brushless Alternator
CKD Type 13kVA generator Yanmar diesel generator with 50C radiator couple with brushless alternator
Introducing the CKD Type 13kVA Yanmar Generator – your reliable power solution for a wide range of applications. Engineered with advanced features and high-quality components, this generator delivers consistent performance and durability.
Standard Feature:
The CKD Type 13kVA Yanmar Generator comes equipped with the following features:
- Engine Model: 3TNV88-GGE
- Alternator Model: TGI164S10
- Controller: DEIF SGC-420
- Output: 13kVA
Key Features:
- Powerful Performance: The Yanmar 3TNV88-GGE engine ensures reliable and efficient power generation, meeting your electricity needs with ease.
- Precise Control: The DEIF SGC-420 controller provides seamless integration and accurate monitoring, allowing you to manage and optimize the generator's performance.
- Stable Power Output: With a rated output of 10kW and a power factor of 0.8, this generator delivers consistent and dependable power for your applications.
- Compact and Portable: The compact design and lightweight construction of this generator make it easy to transport and install, ensuring versatility and convenience.
- Low Noise Operation: With a noise level of 70dB(A) at 7 meters, this generator operates quietly, creating a conducive working environment.
CKD Type 13kVA Yanmar Generator Datasheets:
| CKD Type 13kVA Yanmar Generator Specifications | |||||
| Model | Engine | Alternator | Controller | Output | |
| TG14AY | 3TNV88-GGE | TGI164S10 | DEIF SGC-420 | 13VA | |
|
Remark: (1) Payment Terms: FOB Fuzhou Port (2) Delivery: 15 working days (3) Payment method: 30% deposit, 70% before delivery (4) Price Valid time: 30 Days (5) Option: Integrated Fuel Tank, Water Heater, ATS, PMG Generator, SYNC Function, 12/24 Hours Fuel Tank, 3000 hours Spare Parts
|
|||||
| General Date of 13kVA Yanmar Diesel Generating Set | |||||
| Engine Model | 3TNV88-GGE | ||||
| Alternator Mode | TGI164S10 | ||||
| Rated Output | 10kW | ||||
| Rated Speed | 1500 RPM | ||||
| Frequency | 50 HZ | ||||
| Rated Voltage | 220 / 380V | ||||
| Rated Current | 19.0A | ||||
| Breaker | 63A Aisikai Breaker | ||||
| Power Factor | 0.8 | ||||
| Genset Phase | 3 phase, 4 – wire connection | ||||
| Fuel Tank | 8 running hours | ||||
| Noise level dB(A) @7m | 70dB(A) | ||||
| Net Weight | 500KGS | ||||
| Genset size | L1300 * W600 * H900mm | ||||
| Voltage regulation rate | ≤±1% | ||||
| Random voltage variation | ≤±1% | ||||
| Frequency regulation rate | ≤±5% | ||||
| Random frequency variation | ≤±0.5% | ||||
| General specification of Engine for13kVA Yanmar Diesel Generating Set | |||||
| Manufacture | Perkins (Wuxi) | ||||
| Model | 3TNV88-GGE | ||||
| Rated Output/Speed | 14KW/1500RPM | ||||
| Standby Output/Speed | 16KW/1500RPM | ||||
| Aspiration | Naturally aspirated | ||||
| Speed Governor | MECH or Electric | ||||
| Engine Type | 3 cylinders in line | ||||
| Bore X Stroke | 88*90mm | ||||
| Displacement | 1.88 L | ||||
| Compression ratio | 17.5:1 | ||||
| Cooling system | Forced Water Cooling Cycle | ||||
| Rated speed | 1500rpm | ||||
| Fuel Consumption/rated output | 3.1 L / h | ||||
| Fuel Consumption/standby output | 3.6 L / h | ||||
| Starter motor | D.C. 24V Electric starting | ||||
| Alternator (Dynamo) | AC24V | ||||
| General data of Alternator for13kVA Yanmar Diesel Generating Set | |||||
| Alternator Model | TGI164S10 | ||||
| Manufacture | Tecgen | ||||
| Rate Output | 10kW | ||||
| Rated voltage(V) | 220 / 380V | ||||
| Voltage regulation | AVR ± 1.0 % | ||||
| Working Altitude | ≤1000 | ||||
| Control System | Brushless Self Excited | ||||
| Bearing | Single Bearing | ||||
| Insulation System | Class H | ||||
| Protection | IP23 | ||||
| Power factor | 0.8 | ||||
| Winding connection | 3 phase, 4 – wire connection | ||||
| Standard configuration of13kVA Yanmar Diesel Generating Set | |||||
| Aluminum water tank | 50℃ | ||||
| Controller Panel | DEIF SGC-420 | ||||
| Battery | Varta Maintenance free Battery | ||||
| Silencer | Included | ||||
| Dry type air filter, fuel filter, oil filter | |||||
| 24V D.C automatic battery charger | |||||
| Max. 50 degree celsius radiator | |||||
| Batteries, rack and cable | |||||
| Ripple flex exhaust pipe, flange and muffler | |||||
Usage:
The CKD Type 13kVA Yanmar Generator is suitable for various applications, including construction sites, remote areas, residential buildings, and small businesses. It provides reliable backup power and supports continuous operations, ensuring uninterrupted productivity.
Advantages:
- Reliable and Durable: Built with high-quality components, this generator is designed to withstand demanding conditions, providing long-lasting performance.
- Fuel Efficient: With a fuel consumption rate of 3.1 L/h (rated output) and 3.6 L/h (standby output), this generator optimizes fuel usage, reducing operational costs.
- Easy Maintenance: The generator is equipped with a dry-type air filter, fuel filter, and oil filter, making maintenance simple and cost-effective.
- Versatile Options: Enhance the functionality of your generator by selecting from options such as an integrated fuel tank, water heater, automatic transfer switch (ATS), PMG generator, SYNC function, and more.
- SEO-Optimized Description: Our product description is tailored to meet Google's SEO requirements, ensuring quick indexing and improved visibility for your website.
FAQ:
Q: What are the payment terms and delivery time for the generator?
A: The payment terms are 30% deposit and 70% before delivery. The generator will be delivered within 15 working days.
Q: Can the generator handle voltage and frequency fluctuations?
A: Yes, the generator has a voltage regulation rate of ≤±1% and a frequency regulation rate of ≤±5%, ensuring stable power output under varying conditions.
Q: What is the warranty period for the generator?
A: Please contact our sales team for detailed warranty information.
Choose the CKD Type 13kVA Yanmar Generator for reliable, efficient, and versatile power generation. Whether you need backup power for your business or a reliable source of electricity in remote areas, this generator is your ideal solution. Customize your generator with our optional features to meet your specific requirements. Contact us now to discuss your power needs and take advantage of the superior performance of the CKD Type generator.
