OEM Polycarbonate Plastic Sheets Solid PC Hollow Sheet for Sunshade Roof Canopy
Price:
$3.50/square meters 10-499 square meters
MOQ:
10 square meters
Delivery Time:
Negotiable
Brand:
NIUBAI
Product Description
Products Description
OEM Polycarbonate Plastic Sheets Solid PC Hollow Sheet for Sunshade Roof Canop
| Sample name | PC sheet | Sample appearance | Transparent | |||
| Sample specification | 5mm | Production date | 2023/5/16 | |||
| No | Item | Requirement | Test result | Assessment | Test method | |
| 1 | tensile yield strength,MPA | horizontal | ≥55 | 67.2 | conform | JG/T 347-2012.7.4.1 |
| vertical | ≥55 | 67.7 | conform | JG/T 347-2012.7.4.1 | ||
| 2 | nominal tensile strain at break % | horizontal | ≥60 | 67 | conform | JG/T 347-2012.7.4.1 |
| vertical | ≥60 | 62 | conform | JG/T 347-2012.7.4.1 | ||
| 3 | tensile elastic modulus, MPA | horizontal | ≥2200 | 2.36X 103 | conform | JG/T 347-2012.7.4.1 |
| vertical | ≥2200 | 2.4X 103 | conform | JG/T 347-2012.7.4.1 | ||
| 4 | notched/un-notched charpy impact strength,KJ/m2 | horizontal | ≥6 | 11.8C | conform | JG/T 347-2012.7.4.2 |
| vertical | ≥6 | 10.2C | conform | JG/T 347-2012.7.4.2 | ||
| 5 | dimensional change on heating % | horizontal | ≤5 | 0.615 | conform | JG/T 347-2012.7.4.7 |
| vertical | ≤5 | 3.36 | conform | JG/T 347-2012.7.4.7 | ||
| 6 | thermal expansion coefficient, ºC | horizontal | ≤7.5×10-5 | 6.13×10-5 | conform | JG/T 347-2012.7.4.8 |
| vertical | ≤7.5×10-5 | 6.02×10-5 | conform | JG/T 347-2012.7.4.8 | ||
| 7 | heat distortion temperature,ºC | ≥130 | 134 | conform | JG/T 347-2012.7.4.6 | |
| 8 | light transmittance (5mm), % | / | 87.0 | actual measured value | JG/T 347-2012.7.4.9 | |
,
Application
Product Advantage:
1. Light Transmission
The light transimission of the sheet is quite good which is up to 89%.
2. Weather Resistance
2. Weather Resistance
The weather resistance treatment of anti-UV on the surface of the sheet precents the resin from turning yellow by causing Ultraviolet ray. The UV agent has chemical bond to change Ultraviolet ray into visable light, which has a stable effect on the photsynthesis of plants.
3. Temperature Property
3. Temperature Property
In the temperature from -40C to 120C, the product will not deform.
4. Light Weight
It is light weight, easy to handle and drill, convenient for construsction and procession, when cutting for installation, it is
not easy to be broken.
Packing & Delivery
1. Each sheet covered with PE film or craft paper.
2. The carton or wood box
3.According to customer requirements.
