Product Introduction:
The SIEMENS PLC SIMATIC S7-1500 "AI 8XU/R/RTD/TC HF" 6ES7531-7PF00-0AB0 is an analog input module designed for the SIEMENS SIMATIC S7-1500 series. It features 8 channels that support a variety of analog measurements, including voltage (U), resistance (R), resistance temperature detectors (RTD), and thermocouples (TC). The module operates at high frequencies and includes hardware interrupts with scalable functionality.
Product Information and Specifications:
- Model: AI 8XU/R/RTD/TC HF 6ES7531-7PF00-0AB0
- Analog Inputs: 8 channels
- Measurement Types: Voltage (U), Resistance (R), RTD, TC
- High Frequency Operation: Supported
- Hardware Interrupts: Included, with scalable functionality
Product Attributes:
- Model: AI 8XU/R/RTD/TC HF 6ES7531-7PF00-0AB0
- Analog Inputs: 8 channels
- Measurement Types: Voltage (U), Resistance (R), RTD, TC
- High Frequency Operation: Supported
- Hardware Interrupts: Included, with scalable functionality
The AI 8XU/R/RTD/TC HF module is designed to handle a wide range of analog measurements, including voltage, resistance, RTD, and TC. It supports high-frequency operation, making it suitable for applications that require rapid and accurate analog signal acquisition.
The module also includes hardware interrupts with scalable functionality. This feature allows for immediate response to specific events or conditions, providing flexibility in configuring the interrupt behavior based on the application requirements.
For detailed information on installation, configuration, and usage of the AI 8XU/R/RTD/TC HF module, it is recommended to refer to the product documentation provided by Siemens or contact their technical support. They can provide specific guidance on leveraging the hardware interrupts and scalable functionality to optimize performance and responsiveness in your application.
| Product | |||
| Article Number (Market Facing Number) | 6ES7531-7PF00-0AB0 | ||
| Product Description | SIMATIC S7-1500 analog input module AI 8xU/R/RTD/TC HF, 16 bit resolution, up to 21 bit Resolution at RT and TC, accuracy 0.1%, 8 channels in groups of 1; common mode voltage: 30 V AC/60 V DC, Diagnostics; Hardware interrupts Scalable temperature measuring range, thermocouple type C, Calibrate in RUN; Delivery including infeed element, shield bracket and shield terminal: Front connector (screw terminals or push-in) to be ordered separately | ||
| Product family | SM 531 analog input modules | ||
| Product Lifecycle (PLM) | PM300:Active Product | ||
| Price data | |||
| Region Specific PriceGroup / Headquarter Price Group | 219 / 219 | ||
| List Price | Show prices | ||
| Customer Price | Show prices | ||
| Surcharge for Raw Materials | None | ||
| Metal Factor | None | ||
| Delivery information | |||
| Export Control Regulations | AL : N / ECCN : 9N9999 | ||
| Estimated dispatch time (Working Days) | 1 Day/Days | ||
| Net Weight (kg) | 0,410 Kg | ||
| Packaging Dimension | 16,10 x 19,50 x 5,00 | ||
| Package size unit of measure | CM | ||
| Quantity Unit | 1 Piece | ||
| Packaging Quantity | 1 | ||
| Additional Product Information | |||
| EAN | 4047623406488 | ||
| UPC | 804766243004 | ||
| Commodity Code | 85389091 | ||
| LKZ_FDB/ CatalogID | ST73 | ||
| Product Group | 4501 | ||
| Group Code | R151 | ||
| Country of origin | Germany | ||
| Compliance with the substance restrictions according to RoHS directive | Since: 31.03.2016 | ||
| Product class | A: Standard product which is a stock item could be returned within the returns guidelines/period. | ||
| WEEE (2012/19/EU) Take-Back Obligation | Yes | ||
| REACH Art. 33 Duty to inform according to the current list of candidates |
|
||
| SCIP number | b22d4e0c-93e2-4f75-999c-3edb451c406e | ||
