Perkins 2506c-E15tag1 364kw 400 Kva Perkins Generator Cos 0.8 Lagging 3 Phase
Perkins Diesel Generator Set 2506C - E15TAG1 364/400kw Cos 0.8 Lagging 3 Phase
| Genset Model | YLGF-360PKS | |||||
| Genset | Power Capacity (kw/kva) | 360/450 | ||||
| Rated Voltage (V) | 400/230/110 | |||||
| Rated Current (A) | 648 | |||||
| Rated Frequency (Hz) | 50/60 | |||||
| Rated Speed (rpm) | 1500/1800 | |||||
| Power Factor / Phase | Cos 0.8 Lagging, 3 phase | |||||
| Cooling System | Closed cycle water-cooled with fan,water tank | |||||
| Overall Dimension (L×W×H) (mm) | 4000x1200x 2100 | |||||
| Gross Weight (kg) | 3600 | |||||
| Engine Brand | Perkins | |||||
| Diesel Engine | Engine Model | 2506C-E15TAG1 | ||||
| Prime Power (kw) | 412/450 | |||||
| Engine Structure | 6Cylinder,Vertical,Inline,4 stroke | |||||
| Bore×Stroke (mm) | 137*171 | |||||
| Displacement (L) | 15.2 | |||||
| Compression Ratio | 16:1 | |||||
| Lube Capacity (L) | 62 | |||||
| Fuel System |
| |||||
| Fuel Consumption (g/kw.h) | 216 | |||||
| Lube Consumption (g/kw.h) | 109 | |||||
| Rotating Speed (rpm) | 1500/1800 | |||||
| Speed Governing | electric speed governor | |||||
| Starting Method | By 24V batteries | |||||
| Alternator Brand | YLFDJ | |||||
| Alternator | Alternator Model | YLW-360 | ||||
| Insulation Class | Class H | |||||
| Steady Voltage Regulation | ≤ +/- 0.5% | |||||
| Instant Voltage Ragulation | -15%~+20% | |||||
| Voltage Fluctuation Rate | ≤ +/- 0.5% | |||||
| Steady Frequency Regulation | ≤ +/- 0.5% | |||||
| Instant Frequency Ragulation | -7%~+10% | |||||
| Phase/Connection Type | 3 phase 4 wire/Y type | |||||
| Controller | Controller Brand | HGM6110 | ||||
Payment & Delivery Terms
1.Minimum Order Quantity: 1 set.
2.Packing Details: standard export packing.
3.Delivery Time: 30 working days after receipt of deposit or original L/C.
4.Payment Terms: T/T (30% as deposit,the balance to be paid before delivery) or L/C.
5.Valid time of the quotation: 30 days.
Attachment list
1.Fuel connecting pipes
2.12V DC battery c/w battery cables 2 sets
3.Industrial type silencer c/w stainless steel flexible exhaust bellows
4.Shock absorption rubbers 4 pcs
5.The tool kit and 1 set of manuals (English version).
