5.6KVA 5kva Silent Diesel Generator Sets Air Cooled Household Portable
Price:
$910.00 - $960.00/sets
MOQ:
1
Delivery Time:
Negotiable
Brand:
YLFDJ
Product Description
5.6KVA Silent Diesel Generator Sets air-cooled diesel generator household portable
| Model | YL6700Q(-3) | |
| Frequency(HZ) | 50 | 60 |
| Rated.AC voltage(V) | 220,230,240,110/220,115/230,120/240,220/380,230/400,240/415 | |
| Rated output (KVA) | 4.5 (5.6) | 5.5(6.9) |
| Max. Output (KVA) | 5.0(6.3) | 5.5(6.9) |
| DC output(V) | 12V 8.3A | |
| Phase | Single phase/three phase | |
| Exciter Type | Brush self-excitation | |
| Power factor | 1.0(0.8) | |
| Insulation class | F | |
| Tank capacity [L] | 14.5 | |
| Engine Model | KD186FAE | |
| Starting system | electrical starting | |
| Engine type | Single cylinder, 4 stroke, air cooled, vertical | |
| Bore*stroke(mm) | 86*72 | |
| displacement | 0.418L | |
| compression ratio | 19.5:1 | |
| Speed | 3000 | 3600 |
| Power [Kw] | 5.8 | 6.6 |
| Oil capacity [L] | 1.65 | |
| Fuel | Diesel: 0#(summer), -10#(winter) Use No. 0 diesel in summer, and -10 or -20 diesel in winter. | |
| oil make | SAE10W30 (CD grade or above) Use CD or CD superior 15W-40 oil (or SAE equivalent) | |
| optional features | ATS | |
| telecontrol | ||
| Intelligent digital display panel | ||
| Dimension(L*W*H)(mm) | 910*530*740 | |
| Net weight(kg) | 149 | |
| Structure type | Low noise | |
