SC4H140D2 Sdec Generator 100KVA 80kw Open
SDEC 100KVA 80kw shang chai open diesel generator set
| Genset Model | YLGF-80SC | |||||
| Genset | Power Capacity (kw/kva) | 80 | ||||
| Rated Voltage (V) | 400/230/110 | |||||
| Rated Current (A) | 144 | |||||
| Rated Frequency (Hz) | 50/60 | |||||
| Rated Speed (rpm) | 1500/1800 | |||||
| Power Factor / Phase | Cos 0.8 Lagging, 3 phase | |||||
| Cooling System | Closed cycle water-cooled with fan,water tank | |||||
| Overall Dimension (L×W×H) (mm) | 2200*900*1380 | |||||
| Gross Weight (kg) | 1600 | |||||
| Engine Brand | SHANGCHAI(SDEC) | |||||
| Diesel Engine |
Engine Model | SC4H140D2 | ||||
| Prime Power (kw) | 95 | |||||
| Engine Structure | 4 Cylinder,Vertical,Inline,4 stroke | |||||
| Bore×Stroke (mm) | 105*124 | |||||
| Displacement (L) | 4.3 | |||||
| Compression Ratio | 16:1 | |||||
| Lube Capacity (L) | 13 | |||||
| Fuel System | PT type fuel injection pump | |||||
| Fuel Consumption (g/kw.h) | 195 | |||||
| Lube Consumption (g/kw.h) | 0.5% | |||||
| Rotating Speed (rpm) | 1500/1800 | |||||
| Speed Governing | electronic speed governor | |||||
| Starting Method | By 24V batteries | |||||
| Alternator Brand | YLFDJ | |||||
| Alternator | Alternator Model | YLW-80 | ||||
| Insulation Class | Class H | |||||
| Steady Voltage Regulation | ≤ +/- 0.5% | |||||
| Instant Voltage Ragulation | -15%~+20% | |||||
| Voltage Fluctuation Rate | ≤ +/- 0.5% | |||||
| Steady Frequency Regulation | ≤ +/- 0.5% | |||||
| Instant Frequency Ragulation | -7%~+10% | |||||
| Phase/Connection Type | 3 phase 4 wire/Y type | |||||
| Controller | Controller Brand | HGM6110 | ||||
Payment & Delivery Terms
1.Minimum Order Quantity: 1 set.
2.Packing Details: standard export packing.
3.Delivery Time: 30 working days after receipt of deposit or original L/C.
4.Payment Terms: T/T (30% as deposit,the balance to be paid before delivery) or L/C.
5.Valid time of the quotation: 30 days.
Attachment list
1.Fuel connecting pipes
2.12V DC battery c/w battery cables 2 sets
3.Industrial type silencer c/w stainless steel flexible exhaust bellows
4.Shock absorption rubbers 4 pcs
5.The tool kit and 1 set of manuals (English version).
