Polymer PPTC Resettable Fuse Radial Lead SC16-600SZ0D 6A I Hold 16Vmax 2.80W

V _max

(Vdc)

I _max

(A)

P_dtyp

(W)

Maximum Time

To Trip

Current

(A)

Time

(S)

R _min

(Ω)

R _max

(Ω)

R1_max

(Ω)

I _hold= Hold current: maximum current at which the device will not trip at 25℃ still air.

I _trip= Trip current: minimum current at which the device will always at 25℃ still air.

V _max= Maximum voltage device can withstand without damage at rated current.

I _max= Maximum fault current device can withstand without damage at rated voltage.

T _trip=Maximum time to trip(s) at assigned current.

P_dtyp.= Typical power dissipation: typical amount of power dissipated by the device when in state air environment.

R _min= Minimum device resistance at 25℃ prior to tripping.

R _max= Maximum device resistance at 25℃ prior to tripping.

R1_max= Maximum resistance of device at 25℃ measured one hour after tripping.

Caution: Operation beyond the specified rating may result in damage and possible arcing and flame.

u RoHS Compliant and Halogen-Free

u Radial leaded Devices

u Cured,flame retardant epoxy polymer insulating material meets UL94V-0 requirements

u Operation Current: 6.00A, Maximum Voltage: 16Vdc, Operating Temperature: -40℃ to +85℃

u USB hubs, ports and peripherals

u Power ports

u IEEE1394 ports

u Motor protection

u Computers and peripherals

u General electronics

0.03-1.85A Tin-plated Copper clad steel

2.50-5.00A Tin-plated Copper
