SOCAY Temperature Senso Power NTC Thermistor MF72-SCN8D-7 8Ω 7mm Wide Resistance Range
Price:
USD0.01-0.25/piece
MOQ:
1000
Delivery Time:
5-8 work days
Brand:
SOCAY
Product Description
SOCAY Power NTC Thermistor MF72-SCN8D-7 8Ω 7mm Wide Resistance Range
DATASHEET:
| Features: |
- Operating temperature range: -40~+200℃.
- Wide resistance range.
- High power rating.
- Radial lead resin coated.
- Body size: Ф5mm.
- Cost effective.
| Applications: |
- LED driver circuit.
- Projector.
- Halogen lamp.
- Adapter.
- Transformer.
- Switch mode power supply.
- Electric motor.
| Storage Conditions of Products: |
Storage Temperature: -10℃ ~ +40℃. |
|
| Part Number Code |
|
MF72 SCN 16D - 5 (1) (2) (3) (4)
|
|
(1) MF72: MF72 Series. (2) SCN: Socay NTC. (3) 16D: Zero Power Resistance at 25℃(R25). (4) Body Size: 5=Ф5mm. |
| Electrical Characteristics |
| Resistance at 25℃ ±20% | R25(Ω) | 8(Ω) |
| Max. Permissible Working Current | Imax(A) | 0.5A |
| Resistance under Load (mΩ) | (mΩ) | 1093mΩ |
| Dissipation Factor | δ(mW/℃) | 6mW/℃ |
| Thermal Time Constant | τ(Sec.) | 18Sec. |
| permissible capacitance @240Vac | C(uF) | 47uF |
| Maximum Power Rating(Pmax) |
|
|
| Packing Specifiction | Quantity (pcs/bag) |
| L short | 1000 |
| L long | 500 |
| Structure and Dimensions (Unit: mm) |
|
|
| D max | T max | P max | F | H | Lshort/Llong | d | Type |
| 8.0 | 4.5 | 3.0 | 5±0.5 | -- | 7±1/20±1 | 0.55 | S |
| 8.0 | 4.5 | 3.0 | 5±0.5 | 14.5±1 | 4±1/20±1 | 0.55 | K/V/D |
