1-45T Excavator Quick Hitch Hydraulic Quick Hitch Ex40 Quick coupler

Price Negotiable

Price: $300-10000

MOQ: 1 PC

Delivery Time: 7 days

Brand: RSBM

Product Description

Excavator Hydraulic Cylinder Quick Hitch Ex40 Quick coupler for mini excavator

Product Description

Excavator Hydraulic Quick Hitch

Hydraulic Quick Hitch is one of the most efficient ways to change digger buckets and attachments on a mini digger or excavator.

Fitted to All Excavators and Models.

Combining strength, durability and safety, Hydraulic quick hitch contains a number of features which minimize the risk of any harm being caused during operation as well as providing a robust design to maximize the product lifetime.

Using the Quick Hitch not only saves time and money, it can also help protect your machine against unnecessary wear and tear, it also helps maximize the lifetime of your buckets links and tipping links!

Item/Model	Unit	RSMINI	RS45	RS50/55	RS60/65	RS70/80	RS90	RS100/110
Suitable Excavator	ton	1.5-4	4-7	5-8	9-19	17-23	23-30	33-45
Weight	kg	25	50-60	80	120-130	280-290	420-430	450-580
Length	mm	388	534-545	600	765	924-944	983-1050	1006-1473
Height	mm	246	307	310	388	492	574	558-610
Width	mm	175	258-263	270-280	353-436	449-483	543-568	606-663
Pin to Pin Center Distance	mm	80-150	230-270	290-360	380-420	460-480	473-540	550-620
Forearm Open Width	mm	80-140	155-170	180-200	232-315	306-340	375-411	416-469
Retractable Distance of Oil Cylinder	mm	170-206	205-275	340-450	340-486	256-390	413-590	520-590
Top to Bottom Pin Distance	mm	159	195	195	220	275	300	360
Pin Diameter	mm	25-40	45-50	50-55	60-70	70-80	80-90	90-120
WorkingPressure	bar	32-40	32-40	32-40	32-40	32-40	32-40	32-40
Working Flow	lpm	10-20	10-20	10-20	10-20	10-20	10-20	10-20
