Demolition Reinforced Excavator Concrete Pulverizer Hydraulic

Price Negotiable
Price: $300-10000
MOQ: 1 PC
Delivery Time: 7 days
Brand: RSBM
Product Description
Building Material Shops Demolition Reinforced Hydraulic Concrete Crusher Pulverizer
Product Description

Excavator Pulverizer

This type of pulverizer, which contains a hydraulic system inside which makes it conceived as the first and foremost for demolition of concrete and rebar, is the enhanced version of mechanical type. Hydraulic pulverizer is composed of body, hydraulic cylinder, movable jaw, and fixed jaw. The external hydraulic system offers hydraulic pressure for the hydraulic cylinder to make the movable jaw and fixed jaw open and close to achieve the effect of crushing objects.
Fits 1 to 50-ton excavators (Could be larger for customized).
Characteristic:
Hydraulic pulverizer is the most reliable and effective tool for primary demolition and recycling of reinforced concrete structures. It’s also ideal for secondary demolition, size reduction, and separation of rebar from concrete.
Feature:
1.Large bore dual cylinders: Strong power and excellent durability.
2. Speed-up valve.
3. Lighter and stronger structure: High tensile special steel plate.
4. 360-degree hydraulic rotation (optional)
5. Working efficiency is two or three times of hydraulic breaker.
Applications:
Due to its ability for demolishing and recycling concrete material which could be applied in a wide range of industry fields such as construction works, this type of excavator equipment can be used for both primary and secondary demolition projects.

Hydraulic Pulverizer
Model
RSHP10
RSHP15
RSHP20
RSHP25
RSHP30
Suitable Excavator(Boom Install)
5-8T
8-12T
12-15T
17-22T
22-29T
Weight(Kgs)
900
1550
2500
2900
3600
Suitable Excavator(Arm Install)
8-12T
12-15T
17-22T
22-29T
35-45T
Weight(Kgs)
850
1500
2400
2800
3500
Length(mm)
1300
1740
2410
2615
3100
Width(mm)
350
420
580
624
728
Jaw depth(mm)
450
550
722
899
1130
Max jaw opening(mm)
475
690
838
1018
1214
Work Pressure(Bar)
250
310
350
350
350
Crushing force at tooth tip(Ton)
25
65
70
97
120
Cutting force at primary cutter(Ton)
70
150
230
331
393
