2.2kw VFD 220v Variable Frequency Drive 50hz 60hz ZONCN Inverter Manufacturer In China
ZONCN NZ200 Series Econonic Vector control inverter
Company introduction
ZONCN, Top 5 inverter manufacturer in China which focus on producing inverter for 19 years of experience, the main series NZ100, NZ200, Z2000, Z8000, T9000 and Z5000-BF(IP65/IP54 protection), which are widely used in various applications and have enjoyed high reputation from domestic and abroad market.
What's more, ZONCN is Top 1 brand which used in air compressor industry. And produce for OEM brands have lots of expereince.
We can produce for inverter voltage ranges from 110v to 1140v, inverter powers range from 0.4kw to 2000kw. ZONCN inverter's annual sales quantity is about 1 Million units. And it was listed on the main board of the Shanghai Stock Exchange in August 2023 (Stock Code: 603275).
Inverter Specification
| Model | Input Voltage (V) | Rated output power ( KW) | Rated input current(A) | Rated output current (A) | Motor power ( KW) |
| NZ200-0R4G-2 | 1PH 220V±15% | 0.4 | 5.4 | 2.5 | 0.4 |
| NZ200-0R75G-2 | 0.75 | 7.2 | 5 | 0.75 | |
| NZ200-1R5G-2 | 1.5 | 10 | 7 | 1.5 | |
| NZ200-2R2G-2 | 2.2 | 16 | 11 | 2.2 | |
| NZ200-3R7G-2 | 3.7 | 17 | 16.5 | 3.7 | |
| NZ200-0R4G-4 | 3PH 380V±15% | 0.4 | 3.4 | 1.2 | 0.4 |
| NZ200-0R75G-4 | 0.75 | 3.8 | 2.5 | 0.75 | |
| NZ200-1R5G-4 | 1.5 | 5 | 3.7 | 1.5 | |
| NZ200-2R2G-4 | 2.2 | 5.8 | 5 | 2.2 | |
| NZ200-3R7G/5R5P-4 | 3.7 | 10.7 | 9 | 3.7 | |
| NZ200-5R5G/75R5P-4 | 5.5 | 14.6 | 13 | 5.5 | |
| NZ200-7R5G/11P-4 | 7.5 | 20 | 17 | 7.5 | |
| NZ200-11G/15P-4 | 11 | 26 | 25 | 11 | |
| NZ200-15G/18.5P-4 | 15 | 35 | 32 | 15 | |
| NZ200-18.5G/22P-4 | 18.5 | 38 | 37 | 18.5 | |
| NZ200-22G/30P-4 | 22 | 46 | 45 | 22 | |
| NZ200-30G/37P-4 | 30 | 62 | 60 | 30 | |
| NZ200-37G/45P-4 | 37 | 76 | 75 | 37 | |
| NZ200-45G/55P-4 | 45 | 90 | 90 | 45 | |
| NZ200-55G-4 | 55 | 105 | 110 | 55 | |
| NZ200-75G/90P-4 | 75 | 140 | 150 | 75 | |
| NZ200-90G/110P-4 | 90 | 160 | 176 | 90 | |
| NZ200-110G/132P-4 | 110 | 210 | 210 | 110 | |
| NZ200-132G/160P-4 | 132 | 240 | 253 | 132 | |
| ... | ... | ... | ... | ... | |
| NZ200-450G/500P-4 | 450 | 790 | 790 | 450 |
Inverter Dimension
A. 0.4kw-37kw
B. 45kw-450kw
Inverter Packing
Inverter Application
Inverter Recommendation
