ASTM A269 TP316L Stainless Coil Tubing For Fluid Industry
Stainless Steel Coil Seamless Tubing, ASTM A269 TP316L, 6.35MM*1.24MM*100M, AVG. Wall thickness
Stainless Steel Coil Tubes:
(1) Commodity name: Austenitic Stainless Steel Coil Tubes
(2) Process method: cold drawn/cold pilgered
(3) Material: TP304, TP304L,TP316L,dual grade 317L , 316Ti, TP321
(4) Standard: ASTM ( ASME) ,EN, DIN, JIS and etc.
(5) Specifications:a) O.D.:1/4" -3/4"
b) W.T.:0.028"- 0.065"
c) Length:customized, max:1000m/pc.
(6) Delivery conditions: annealed & pickled
(7) Applications: widely used in petrol, chemical, pharmacy, foodstuff, machinery, spaceflight, war industry.
(8) boiler gas, hot water heating parts, hardware, shipping, power and other industries.
(9) Packing: packed by weaving bags, then protected by seaworthy wooden case.
Material Grade:
| American Standard | Austenitic Steel: TP304,TP304L,TP304H, TP304N, TP310S,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L… Duplex Steel : S32101,S32205,S31803,S32304,S32750, S32760 Others:TP405,TP409, TP410, TP430, TP439,... |
| Europen Standard | 1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501 |
| GOST | 08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т, 06ХН28МДТ |
• Diameter from 3mm (0.118”) to 25.4mm (1.00”) OD.
• Wall thickness from 0.5mm (0.020”) to 3mm (0.118”).
• OD tolerance +/- 0.005” (0.13mm) and +/- 10% wall thickness. Other tolerances are available on request.
• Coil lengths up to 1500m (5,000ft) without orbital joints depending on product dimensions.
• Coil lengths up to 13,500m (45,000ft) with orbital joints.
• Encapsulated, PVC coated or bare line tubing.
• Available on wooden or steel spools.
| Imperial size | Metric size | ||
| OD inch |
WT inch |
OD mm |
WT mm |
| 1/8 (0.125) | 0.028 | 3.18 | 0.71 |
| 0.035 | 3.18 | 0.89 | |
| 3/16 (0.188) | 0.028 | 4.76 | 0.71 |
| 0.035 | 4.76 | 0.89 | |
| 0.049 | 4.76 | 1.24 | |
| 1/4 (0.250) | 0.035 | 6.35 | 0.89 |
| 0.049 | 6.35 | 1.24 | |
| 0.065 | 6.35 | 1.65 | |
| 0.083 | 6.35 | 2.11 | |
| 3/8 (0.375) | 0.035 | 9.53 | 0.89 |
| 0.049 | 9.53 | 1.24 | |
| 0.065 | 9.53 | 1.65 | |
| 0.083 | 9.53 | 2.11 | |
| 1/2 (0.500) | 0.035 | 12.7 | 0.89 |
| 0.049 | 12.7 | 1.24 | |
| 0.065 | 12.7 | 1.65 | |
| 0.083 | 12.7 | 2.11 | |
The quality of our products for the control line in oil and gas sector is assured not just during the controlled manufacturing process but also by way of finished product testing. Typical tests include:
• Non-destructive tests
• Hydrostatic tests
• Surface finish controls
• Dimensional accuracy measurements
• Flare and coning tests
• Mechanical and chemical property testing
