51.2V 200Ah Power Wall Battery LiFePO4 Solar Energy Storage Battery For Home
Joypo 51.2V 200Ah LiFePO4 Power Wall Solar Energy Storage Battery For Home
Features:
1. Can act as a UPS battery to meet residential or office daily electricity demand.
2. With the LCD screen, shows the battery status in real-time.
3. With smart BMS, provide complete protection from short-circuit, overcharge, over-discharge, overcurrent, over-voltage, and so on.
4. Long cycle life of more than 6000 times, durable and stable performance.
5. Support up to 16 pieces connected in parallel.
6. CAN/RS485/RS232 Communication optional.
7. With handles, easy to carry.
| Project name | Standard requirement |
| Operating Voltage | 43.2~58.4V |
| Battery capacity | 200Ah |
| Battery energy | 10240Wh |
| Weight | About 87kg |
| Dimension | L650 X W580 X 230mm |
| Enclosure material | 1.5mm cold rolled iron plate |
| Continuous charging current | 100A |
| Peak discharge current | 300A (duration 3S) |
| Rated discharge current | 200A |
| Charging cut-off voltage | 58.4V |
| Discharge cut-off voltage | 43.2V |
| charging method | CC-CV |
| Self-discharge | ≤2% per month |
| Temperature characteristics |
Charging Temperature:0℃～45℃ Discharge Temperature:-20℃～55℃ |
| Storage temperature | 0～45℃ |
| Communication | CAN/RS485/RS232 |
| Cycle life | 6000 times |
| Parallel rule | Up to 16 packs can be connected in parallel |
| Battery protection | Cell balancing, overcharging, over-discharge, overcurrent, overvoltage, short circuit, and so on |
Advantages:
1. Energy independence
2. Reduce your electricity bill
3. Keep your appliances running during power shortages
4. Higher property values
5. Environmental benefits
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
