72V 200Ah Residential Solar Battery Storage Caravan Lifepo4 Energy Storage Battery

Name: 72V 200Ah Residential Solar Battery Storage Caravan Lifepo4 Energy Storage Battery
Brand: Shenzhen Renergy Power Technology Co., Ltd.

Price Negotiable

Price: Negotiable

MOQ: 50

Delivery Time: 15 - 30 Days

Brand: RPT

Product Description

72V 200Ah Lifepo4 Rechargeable Lithium ion Battery Pack for EV RV Caravan Marine Boat

Product Paramenters

Nominal Capacity	100Ah	120Ah	150Ah	200Ah	300Ah
Energy	1280WH	1536WH	1920WH	2560WH	3840WH
Internal Resistance	≤10mΩ
Cycle Life	>4000 cycles@1C 100% DOD
Months Self Discharge	<3%
Efficiency of Charge	100%@0.5C
Efficiency of Discharge	96-99% @1C
Charge Cut-off Voltage	14.6±0.2V
Charge Mode	0.2C to 14.6V, then 14.6V charge current to 0.02C(CC/CV)
Recommend Charge Current	20A	20A	20A	20A	20A
Max. Charge Current	100A	100A	100A	100A	100A
Max. Continuous Discharge Current	100A	100A	100A	100A	100A
Max. Pulse Current	200A	200A	200A	200A	200A
Discharge Cut-off Voltage	10V
Charge Temperature	0ºC to 45ºC(32F to 113F)@60±25% Relative Humidity
Discharge Temperature	-20ºC to 60ºC(-4F to 140F)@60±25% Relative Humidity
Storage Temperature	0ºC to 40ºC(32F to 104F)@60±25% Relative Humidity
Water Dust Resistance	IP65
Cell&Method	4S1P
Package	ABS plastic case
Dimensions(in./mm.)	329172214	329172214	483170240	525240220	525270220
Weight(lbs./kg.)	13.5	15	25	28	32
Terminal	M8
Display screen	Optional
Bluetooth	Optional
